6V Geared Motor for Vending Machine, Robot with 32mm Gearbox and 6mm D-shape Shaft

Get Latest Price

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Payment Type:	T/T or L/C

Product Description

Gearbox: Φ 32mm

Material: die-casting zinc

Shaft: Ø 6mm inline carbon steel shaft with custom D-shape and length

DC motor (D x L): Φ32 x 19.3mm

Rotation: CCW/CW, reversible

Gears: spur metal gears

Lubrication: grease filled

Way of commutation: metal brush

Reduction ratios: 1/15, 1/17.3, 1/40, 1/46, 1/51.8, 1/105,1/136, 1/155, 1/278, 1/316, 1/409, 1/466, 1/732, 1/1,228 and1/1.397.3

Performance:

Ratio: 1/155
Voltage: 12V DC
At no load:
- Speed: 707.3rpm
- Current: 0.12A
At on load:
- Speed: 585.3rpm
- Current: 0.46A
- Torque: 0.2kg.cm
Options: technical data like voltage, speed, torque, shaft direction, shaft length, D-shaped size and length

Suitable for vending machines, robots and dispenser

Ratio: 1/155

Voltage: 12V DC

At no load:

At on load:

Options: technical data like voltage, speed, torque, shaft direction, shaft length, D-shaped size and length

Speed: 707.3rpm

Current: 0.12A

Speed: 585.3rpm

Current: 0.46A

Torque: 0.2kg.cm
