8mm and 3V Micro DC motor with high speed for epilator
  • 8mm and 3V Micro DC motor with high speed for epilator
8mm and 3V Micro DC motor with high speed for epilator

8mm and 3V Micro DC motor with high speed for epilator

Get Latest Price
Payment Type:
T/T, L/C, Western Union, Cash, PayPal or MoneyGram
Quantity:

Your message must be between 20 to 2000 characters

Contact Now
Basic Info
Basic Info
Payment Type: T/T, L/C, Western Union, Cash, PayPal or MoneyGram
Product Description
Product Description
  • Measuring conditions:
    • Rated voltage: 3V DC
    • Motor position: to be measured with motor horizontally held
    • Environmental temperature: +5 - +35°C
    • Envirenmental humidity: 40%-85% RH
    • Staring voltage: ≤1.5V
    • Electrical characteristics (at initial stage after 30 seconds run in):
      • No load:
        • Speed: 22500 ±10%rpm
        • Current: ≤55mA
      • At on load:
        • Torque: 0.5g.cm
        • Speed: 15800 ±10%rpm
        • Current: ≤120mA
      • At stall:
        • Torque: ≥1.3g.cm
        • Current: ≤280mA
      • Direction of rotation: CW (clockwise when viewing from the output shaft end with positive voltage applied to positive terminal)
    • Dimension:
      • Diameter of the housing: 8mm
      • Length of the housing: 10mm
      • Width of the housing: 6mm
      • Diameter of the shaft: 1mm
  • Features:
    • NdFeB magnet
    • Precious metal brush
    • Stainless steel shaft
    • Constructions of motor:
      • 2-pole stator
      • Sr ferrite permanent magnet
      • 3, 5, 7, 8, 9, 12 slots armature
      • Silicon-steel lamination with epoxy coating
      • High carbon steel shaft
      • Cu-Ag alloys commutator
      • Copper graphite brushes
      • Be-Cu leaf-brush commutating system
      • SECD round/flat shape housing
      • SECD end cap/PA66+fiber end cap
      • Cylinder (self-aligning) sintered bush
      • 155 degrees (class F) copper wire
  • Rated voltage: 3V DC
  • Motor position: to be measured with motor horizontally held
  • Environmental temperature: +5 - +35°C
  • Envirenmental humidity: 40%-85% RH
  • Staring voltage: ≤1.5V
  • Electrical characteristics (at initial stage after 30 seconds run in):
    • No load:
      • Speed: 22500 ±10%rpm
      • Current: ≤55mA
    • At on load:
      • Torque: 0.5g.cm
      • Speed: 15800 ±10%rpm
      • Current: ≤120mA
    • At stall:
      • Torque: ≥1.3g.cm
      • Current: ≤280mA
    • Direction of rotation: CW (clockwise when viewing from the output shaft end with positive voltage applied to positive terminal)
  • Dimension:
    • Diameter of the housing: 8mm
    • Length of the housing: 10mm
    • Width of the housing: 6mm
    • Diameter of the shaft: 1mm
  • No load:
    • Speed: 22500 ±10%rpm
    • Current: ≤55mA
  • At on load:
    • Torque: 0.5g.cm
    • Speed: 15800 ±10%rpm
    • Current: ≤120mA
  • At stall:
    • Torque: ≥1.3g.cm
    • Current: ≤280mA
  • Direction of rotation: CW (clockwise when viewing from the output shaft end with positive voltage applied to positive terminal)
  • Speed: 22500 ±10%rpm
  • Current: ≤55mA
  • Torque: 0.5g.cm
  • Speed: 15800 ±10%rpm
  • Current: ≤120mA
  • Torque: ≥1.3g.cm
  • Current: ≤280mA
  • Diameter of the housing: 8mm
  • Length of the housing: 10mm
  • Width of the housing: 6mm
  • Diameter of the shaft: 1mm
  • NdFeB magnet
  • Precious metal brush
  • Stainless steel shaft
  • Constructions of motor:
    • 2-pole stator
    • Sr ferrite permanent magnet
    • 3, 5, 7, 8, 9, 12 slots armature
    • Silicon-steel lamination with epoxy coating
    • High carbon steel shaft
    • Cu-Ag alloys commutator
    • Copper graphite brushes
    • Be-Cu leaf-brush commutating system
    • SECD round/flat shape housing
    • SECD end cap/PA66+fiber end cap
    • Cylinder (self-aligning) sintered bush
    • 155 degrees (class F) copper wire
  • 2-pole stator
  • Sr ferrite permanent magnet
  • 3, 5, 7, 8, 9, 12 slots armature
  • Silicon-steel lamination with epoxy coating
  • High carbon steel shaft
  • Cu-Ag alloys commutator
  • Copper graphite brushes
  • Be-Cu leaf-brush commutating system
  • SECD round/flat shape housing
  • SECD end cap/PA66+fiber end cap
  • Cylinder (self-aligning) sintered bush
  • 155 degrees (class F) copper wire
