Rigid-flex Electronic Circuit, Rigid 1.6mm, Flex 0.15mm Black Soldermask PCB, Double Sided
  • Rigid-flex Electronic Circuit, Rigid 1.6mm, Flex 0.15mm Black Soldermask PCB, Double Sided
Rigid-flex Electronic Circuit, Rigid 1.6mm, Flex 0.15mm Black Soldermask PCB, Double Sided

Rigid-flex Electronic Circuit, Rigid 1.6mm, Flex 0.15mm Black Soldermask PCB, Double Sided

Get Latest Price
Payment Type:
Telegraphic Transfer in Advance (Advance TT, T/T)
Quantity:

Your message must be between 20 to 2000 characters

Contact Now
Basic Info
Basic Info
Payment Type: Telegraphic Transfer in Advance (Advance TT, T/T)
Product Description
Product Description
  • Specifications:
    • Material: FR-4
    • Layers: 2
    • Rigid: 1.6mm
    • Flex: 0.15mm
    • Copper thickness: 1oz
    • Solder mask: black
    • Surface finish: ENIG
    • Buried and blind hole: not supported
    • Applications: gas detectors, remote controls, telecommunicationproducts
    • Reference: our production capability for rigid PCB
    • Layers: 1 to 28
    • Board finished thickness: 0.21 to 7.0mm
    • Materials: FR-4, CEM-1, CEM-3, high TG, FR4 halogen-free androgers
    • Maximum finished board size: 23 x 25mm (580 x 900mm)
    • Minimum drilled hole size: 3 mils (0.075mm)
    • Minimum line width: 3 mils (0.075mm)
    • Minimum line spacing: 3 mils (0.075mm)
    • Surface finish/treatment: HASL/HASL lead free, HAL, chemicaltin, chemical gold, immersion silver, gold, OSP and goldplating
    • Copper thickness: 0.5 to 7.0oz
    • Solder mask color: green/yellow/black/white/red/blue
    • Copper thickness in hole: >25.0μm (>1mil)
    • Inner packing: vacuum packing/plastic bag
    • Outer packing: standard carton packing
    • Shape tolerance: ±0.13
    • Hole tolerance:
      • PTH: ±0.076
      • NPTH: ±0.05
    • Certificate: UL
    • Special requirements: buried and blind via + controlledimpedance + BGA
    • Profiling: punching, routing, V-cut and beveling
    • Provides OEM services to all sorts of printed circuit boardassembly as well as electronic encased products
