16 Ports 10/100M/1000M IEEE 802.3at PoE Midspan Injector

Get Latest Price

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Payment Type:	T/T in Advance

Product Description

16 Ports Gigabit IEEE 802.3at PoE Injector

Each port transfer 36W power (4,5) +, (7,8) -, used in AF/AT POE applications
Each port with a Giga network transformer, high-immunity for noise
Independent overload, short-circuit protections for each port, auto-start when fault removed
High-inrush current stand ability, optimized for large capacitor loading applications
Port forced power, adapt to standard PD and non-standard PD applications, PD splitter is also provided
Clear LED indication for each port, off for no loading, light for loading, flash for protection
Can power to 100m long distance applications
10/100/1,000Mbps compliance
RJ45 signal port surge protection, stand 10/700us surge up to 2KV DM and 6KV CM
Wide temperature range: -20 to 55°C
Temperate adjust fan or nature cooling (150W power) extend system life time
System reliability: MTBF >100,000 hours at 220V AC full loading 25°C
With CE and RE EN55022, CLASS B compliance
High-efficiency power supply inside, 100 to 240V AC wide range input
High-power factor due to PFC circuit
Power supply with input low-voltage and over-voltage, output over-voltage, over-temperature, output over-current and output short-circuit protections
Surge protection: power input port can stand 4KV DM and 5KV CM
The limited power of each port can be adjusted according to requirements

Each port transfer 36W power (4,5) +, (7,8) -, used in AF/AT POE applications

Each port with a Giga network transformer, high-immunity for noise

Independent overload, short-circuit protections for each port, auto-start when fault removed

High-inrush current stand ability, optimized for large capacitor loading applications

Port forced power, adapt to standard PD and non-standard PD applications, PD splitter is also provided

Clear LED indication for each port, off for no loading, light for loading, flash for protection

Can power to 100m long distance applications

10/100/1,000Mbps compliance

RJ45 signal port surge protection, stand 10/700us surge up to 2KV DM and 6KV CM

Wide temperature range: -20 to 55°C

Temperate adjust fan or nature cooling (150W power) extend system life time

System reliability: MTBF >100,000 hours at 220V AC full loading 25°C

With CE and RE EN55022, CLASS B compliance

High-efficiency power supply inside, 100 to 240V AC wide range input

High-power factor due to PFC circuit

Power supply with input low-voltage and over-voltage, output over-voltage, over-temperature, output over-current and output short-circuit protections

Surge protection: power input port can stand 4KV DM and 5KV CM

The limited power of each port can be adjusted according to requirements
