2.488Gbps CWDM SFP Optical Transceiver, 80km Reach

Get Latest Price

Payment Type:: Telegraphic Transfer in Advance (Advance TT, T/T)

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Payment Type:	Telegraphic Transfer in Advance (Advance TT, T/T)

Product Description

Model: CSFP-48XX-L8

Features:

Data-rate of 2.488Gbps operation
18 CWDM DFB wavelengths laser and APD photodetector for 80km transmission
Compliant with SFP MSA and SFF-8472 with duplex LC receptacle
Digital diagnostic monitoring: internal calibration or external calibration
Compliant with the RoHS Directive
+3.3V single power supply
Operating case temperature:
- Standard: 0 to +70°C

Applications:

SDH STM-16 and SONET OC-48 system
2x fiber channel
Switch to switch interface
Switched backplane applications
Router/server interface
Other optical transmission systems

Description:

The SFP transceivers are high performance, cost effective modules supporting data-rate of 2.488Gbps and 80km transmission distance with SMF
The transceiver consists of three sections: a uncooled CWDM DFB laser transmitter, a APD photodiode integrated with a trans-impedance preamplifier (TIA) and MCU control unit
All modules satisfy class I laser safety requirements
The transceivers are compatible with SFP multi-source agreement (MSA) and SFF-8472
For further information, refer to SFP MSA

Absolute maximum ratings:

Supply voltage (Vcc): -0.5 to 4.5V
Storage temperature (Ts): -40 to 85°C
Operating humidity: 5 to 85%

Recommended operating conditions:

Operating case temperature (standard Tc): 0 to +70°C
Power supply voltage (Vcc): 3.13 to 3.3V

Data-rate of 2.488Gbps operation

18 CWDM DFB wavelengths laser and APD photodetector for 80km transmission

Compliant with SFP MSA and SFF-8472 with duplex LC receptacle

Digital diagnostic monitoring: internal calibration or external calibration

Compliant with the RoHS Directive

+3.3V single power supply

Operating case temperature:

Standard: 0 to +70°C

Standard: 0 to +70°C

SDH STM-16 and SONET OC-48 system

2x fiber channel

Switch to switch interface

Switched backplane applications

Router/server interface

Other optical transmission systems

The SFP transceivers are high performance, cost effective modules supporting data-rate of 2.488Gbps and 80km transmission distance with SMF

The transceiver consists of three sections: a uncooled CWDM DFB laser transmitter, a APD photodiode integrated with a trans-impedance preamplifier (TIA) and MCU control unit

All modules satisfy class I laser safety requirements

The transceivers are compatible with SFP multi-source agreement (MSA) and SFF-8472

For further information, refer to SFP MSA

Supply voltage (Vcc): -0.5 to 4.5V

Storage temperature (Ts): -40 to 85°C

Operating humidity: 5 to 85%

Operating case temperature (standard Tc): 0 to +70°C

Power supply voltage (Vcc): 3.13 to 3.3V
