Patch Antenna, Compact Structure and Nice Design, Patched by 3M Glues, 2dBi Gain
  • Patch Antenna, Compact Structure and Nice Design, Patched by 3M Glues, 2dBi Gain
Patch Antenna, Compact Structure and Nice Design, Patched by 3M Glues, 2dBi Gain

Patch Antenna, Compact Structure and Nice Design, Patched by 3M Glues, 2dBi Gain

Get Latest Price
Payment Type:
T/T, Western Union, L/C at Sight
Quantity:

Your message must be between 20 to 2000 characters

Contact Now
Basic Info
Basic Info
Payment Type: T/T, Western Union, L/C at Sight
Product Description
Product Description
  • Specifications:
    • Compact structure and nice design
    • Patched by 3M glues, which is applied to car security and WAMR
    • Electrical:
      • Frequency range: 890-960/1710-2170MHz
      • Band-width: 70/460MHz
      • Gain: 2.0dBi
      • VSWR: ≤2.0
      • Nominal impedance: 50Ω
      • Polarization: vertical
      • Power: 50W (maximum)
      • Connector: SMA
    • Mechanical:
      • Cable length: 3m
      • Antenna dimensions: 115.5 x 21.5 x 5.5mm
      • Weight: 55g
      • Installation way: adhesive
      • Temperature range: -40 to 60°
      • Humidity range: 5 to 95% RH
  • Compact structure and nice design
  • Patched by 3M glues, which is applied to car security and WAMR
  • Electrical:
    • Frequency range: 890-960/1710-2170MHz
    • Band-width: 70/460MHz
    • Gain: 2.0dBi
    • VSWR: ≤2.0
    • Nominal impedance: 50Ω
    • Polarization: vertical
    • Power: 50W (maximum)
    • Connector: SMA
  • Mechanical:
    • Cable length: 3m
    • Antenna dimensions: 115.5 x 21.5 x 5.5mm
    • Weight: 55g
    • Installation way: adhesive
    • Temperature range: -40 to 60°
    • Humidity range: 5 to 95% RH
  • Frequency range: 890-960/1710-2170MHz
  • Band-width: 70/460MHz
  • Gain: 2.0dBi
  • VSWR: ≤2.0
  • Nominal impedance: 50Ω
  • Polarization: vertical
  • Power: 50W (maximum)
  • Connector: SMA
  • Cable length: 3m
  • Antenna dimensions: 115.5 x 21.5 x 5.5mm
  • Weight: 55g
  • Installation way: adhesive
  • Temperature range: -40 to 60°
  • Humidity range: 5 to 95% RH
