Product Description

Composed of an OLED panel, driver ICs and FPC (without polarizer)

The 2.4-inch display area contains 240 x RGB x 320 dots

Size: 2.40 inches

Resolution: 240 x RGB x 320

Display color: 16M color (24bit per pixel)/65K color (16bit per pixel)

Interface: 8bit parallel data with MPU (8080-series MPU)

Dot sizes: 0.025 x 0.131mm

Dot pitch: 0.051 x 0.153mm

Pixel pitch: 0.153 x 0.153mm

Outline dimensions: 42.92 x 69.46 x 1.4mm

Active area: 36.72 x 48.96mm

Controller IC: DA8620

Drive duty: 1/320 duty

Operating temperatures: -20 to 70°C

Storage temperature: -30 to 80°C
