LED Display Screen, 3-in-1 SMD and 16-bit Correction Scale Level

Get Latest Price

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Payment Type:	Telegraphic Transfer in Advance (Advance TT, T/T)

Product Description

Specifications:

Pixel pitch: 8mm

SMD 3-in-1

Pixel construction: one chip with 3 color (3-in-1)

Module resolution (L x H): 32 x 16mm/512 pixel dots

Brightness of white: 1,500cd/m³ at least

Optimal viewing distances: 5 to 38m

Gray scale: 10 bits/1,024 levels

Display color: 1,024 x 1,024 x 1,024P/1 billion

Viewing angle (H/V): 150/120°

Refresh rate: 240Hz at least

Driving mode: constant driving 1/8 scan

Brightness adjustments: 0 to 100% with 8 levels automatic

Gamma corrections: -5.0 to 5.0

Correction scale level: 16 bits

Frame frequencies: 60 to 85Hz

Color temperatures: 5,000 to 9,300K (control by the software)

Input source supported: S-video, VGA, DVI, SDI and HD-SDI

Lifespan: 100,000 hours at least

MTBF: 5,000 hours at least

Out of control rate: 3/10,000 at most
