Product Description

Pixel pitch: 10mm

Resolutions: 16 x 16 pixels

Module dimensions: 160 x 160mm

Pixel configuration: 1R1G1B

Density: 10,000 dots/m²

Cabinet parameters:

Cabinet dimensions: 960 x 960mm
Cabinet resolutions: 96 x 96mm
Module quality: 6 x 6 pieces

Main technical parameters:

LED standard: DIP346
Best viewing distance: 10 to 100m
Best viewing angle:
- Horizontal: 120°
- Vertically: 55°
Brightness: ≥6,500cd/m²
Drive mode: constant driving,1/4 scan
Exchange frame frequency: ≥60Hz
Refresh rate: ≥350Hz
Grey grade: 1,024 levels
Protection rate: PI65
Control mode: synchronization
Working voltage: 380V ± 10%
Power consumption: 800W/m² (maximum)
Working environment temperatures: -20 to 50°C
Screen lifespan: ≥100,000 hours
Blind DOT rate: below 0.0001
Computer operating systems: Microsoft's Windows 98, XP, 2000and more
Video signals: RF, S-video, RGB, RGBHV, YUV and more
Control system: DVI graphics card, sending card and receivingcard
PC display mode:
Software: LED studio

With CE, FCC and RoHS marks

Cabinet dimensions: 960 x 960mm

Cabinet resolutions: 96 x 96mm

Module quality: 6 x 6 pieces

LED standard: DIP346

Best viewing distance: 10 to 100m

Best viewing angle:

Horizontal: 120°
Vertically: 55°

Brightness: ≥6,500cd/m²

Drive mode: constant driving,1/4 scan

Exchange frame frequency: ≥60Hz

Refresh rate: ≥350Hz

Grey grade: 1,024 levels

Protection rate: PI65

Control mode: synchronization

Working voltage: 380V ± 10%

Power consumption: 800W/m² (maximum)

Working environment temperatures: -20 to 50°C

Screen lifespan: ≥100,000 hours

Blind DOT rate: below 0.0001

Computer operating systems: Microsoft's Windows 98, XP, 2000and more

Video signals: RF, S-video, RGB, RGBHV, YUV and more

Control system: DVI graphics card, sending card and receivingcard

PC display mode:

Software: LED studio

Horizontal: 120°

Vertically: 55°
