1.44-inch TFT Display, 128 RGB x 128P Resolution, 8/16-bit Interface and LED Backlight

Get Latest Price

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Payment Type:	Telegraphic Transfer (TT,T/T)

Product Description

Screen size: 1.44 inches (diagonal)

Resolutions (W x H): 128 x RGB x 128 pixels

Display modes: normally white, transmissive

Driver element: a-Si TFT active matrix

Color depth: 262,000K

Viewing direction: 12'O clock

Viewing angle: (L/R/U/D) 50/50/50/30°

Brightness: 200cd/m²

Color configuration RGB vertical stripe

Backlight unit: LED x 2 pieces

Interface: MCU 80-system 8-bit data bus 18-pin

Touch panel: without (touch panel mode for wire resistance/optional)

Drive IC ST7735R

Dimensions:

Outline (W x H x T): 30.30x34.41x2.4mm

Viewing area (W x H): 25.49x26.49mm

Active area (W x H): 25.49x26.49mm

Pixel pitch (W x H): 0.0727x0.219mm

Dots size (W x H): 0.0607x0.207mm
