15-inch Industrial LCD PC Monitor, 6U Rack Mount, USB/RS232 Touchscreen, VGA IN, 12V DC IN, OEM/DOM

15-inch Industrial LCD PC Monitor, 6U Rack Mount, USB/RS232 Touchscreen, VGA IN, 12V DC IN, OEM/DOM

Get Latest Price

Payment Type:: Telegraphic Transfer in Advance (Advance TT, T/T)

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Payment Type:	Telegraphic Transfer in Advance (Advance TT, T/T)

Product Description

Mechanism:

Front panel: aluminum front panel
Ingress protection meet with NEMA4, IP65
Chassis: heavy steel chassis with SECC
Color: matte black

System information:

LCD: 15" TFT LCD industrial grade
Input signal: RGB (DB-15 VGA interface)
Keys: 1 x OSD keyboard for LCD adjustment (multi-language)
Reliability: MTBF 50,000hrs, MTTR 0.5hrs
Mounting: rack mounting
Power input: 1 x Phoenix terminal DC in
Shock: 10g peak acceleration (11 ms duration)
Vibration: 5-17Hz/1.0mm amplitude, 17-200Hz/1.0g acceleration
Dimension (W x H x D): 483 x 310 x 49mm
Weight: about 7kg

LCD:

LCD size: 15" TFT LCD
Aspect ratio: 4:3
Resolution: 1,024 x 768p
Luminance: 300cd/m²
Contrast ratio: 1,500:1
Backlight: LED
Colors: 16.7M colors

Touchscreen:

Interface: RS-232 (USB Interface Optional)
Lifespan: 10 million times/point
Light transmission: 80 %
Type: 5-wire analog resistive touchscreen

I/O ports:

1 x DB-15 VGA video in
1 x COM (or 1 x USB, touchscreen)
1 x power in interface

Power:

System power requirement: 12V DC power input
Power adapter:
- Input: 100-250V AC/47-63Hz
- Output: 48W adapter (12V at 4A)

Environmental:

Operating temperature: -10-60°C (14-140°F)
Relative humidity: 0-90% relative humidity, non-condensing
Storage temperature: -20-70°C (-4-158°F)

Options:

Strengthen tempered glass: optional
Audio in and 2 x 2W speaker out: optional
DVI/HDMI video in: optional

Front panel: aluminum front panel

Ingress protection meet with NEMA4, IP65

Chassis: heavy steel chassis with SECC

Color: matte black

LCD: 15" TFT LCD industrial grade

Input signal: RGB (DB-15 VGA interface)

Keys: 1 x OSD keyboard for LCD adjustment (multi-language)

Reliability: MTBF 50,000hrs, MTTR 0.5hrs

Mounting: rack mounting

Power input: 1 x Phoenix terminal DC in

Shock: 10g peak acceleration (11 ms duration)

Vibration: 5-17Hz/1.0mm amplitude, 17-200Hz/1.0g acceleration

Dimension (W x H x D): 483 x 310 x 49mm

Weight: about 7kg

LCD size: 15" TFT LCD

Aspect ratio: 4:3

Resolution: 1,024 x 768p

Luminance: 300cd/m²

Contrast ratio: 1,500:1

Backlight: LED

Colors: 16.7M colors

Interface: RS-232 (USB Interface Optional)

Lifespan: 10 million times/point

Light transmission: 80 %

Type: 5-wire analog resistive touchscreen

1 x DB-15 VGA video in

1 x COM (or 1 x USB, touchscreen)

1 x power in interface

System power requirement: 12V DC power input

Power adapter:

Input: 100-250V AC/47-63Hz
Output: 48W adapter (12V at 4A)

Input: 100-250V AC/47-63Hz

Output: 48W adapter (12V at 4A)

Operating temperature: -10-60°C (14-140°F)

Relative humidity: 0-90% relative humidity, non-condensing

Storage temperature: -20-70°C (-4-158°F)

Strengthen tempered glass: optional

Audio in and 2 x 2W speaker out: optional

DVI/HDMI video in: optional
