0.91-inch OLED Display Module with 4-wire SPI Interface and White Display Color

Get Latest Price

Payment Type:: 30% Deposit and 70% T/T before Shipment

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Payment Type:	30% Deposit and 70% T/T before Shipment

Product Description

Overview:

This is an OLED full color 128x32 dot-matrix display module
The characteristics of this display module are high-brightness, self-emission, high-contrast ratio, slim/thin outline, wide viewing angle, wide temperature range and low-power consumption

Features:

Display color: white
Dot matrix: 128x32
Driver IC: SSD1306Z
Interface: 4-wire SPI
Wide range of operating temperature: -40 to 70°C
Dot-matrix (WxH): 128x32mm
Dot size (WxH): 0.159x0.159mm
Dot pitch (WxH): 0.175x0.175mm
Aperture: 82%
Active area (WxH): 22.38x5.58mm
Panel size (WxHxT): 30x11.5x1.05mm
Module size (WxHxT): 46.3x11.5x1.28mm
Diagonal A/A size: 0.91-inch
Module weight: 0.92 ±10% gram

This is an OLED full color 128x32 dot-matrix display module

The characteristics of this display module are high-brightness, self-emission, high-contrast ratio, slim/thin outline, wide viewing angle, wide temperature range and low-power consumption

Display color: white

Dot matrix: 128x32

Driver IC: SSD1306Z

Interface: 4-wire SPI

Wide range of operating temperature: -40 to 70°C

Dot-matrix (WxH): 128x32mm

Dot size (WxH): 0.159x0.159mm

Dot pitch (WxH): 0.175x0.175mm

Aperture: 82%

Active area (WxH): 22.38x5.58mm

Panel size (WxHxT): 30x11.5x1.05mm

Module size (WxHxT): 46.3x11.5x1.28mm
