8CH H.264 960H Compression DVR, Supports iPhone, Blackberry and Android/Support MAC/P2P Function

Get Latest Price

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Payment Type:	T/T, L/C, Western Union or MoneyGram

Product Description

H.264 960H 8CH DVR

Video compression: H.264

Video system: PAL/NTSC

Operation system: Linux(embedded)

Video-input/output: 8CH input /1CH output(BNC)

Audio input/output: 8CH input /1CH output(RCA)

Display resolution:

Display feature:

Record resolution:

PAL:D1 360 × 288 (CIF),720 x 288 (HD1), 720 x 576(D1) 960H: 480 × 288 (WCIF), 960 × 288 (WHD1), 960 × 576(WD1)
NTSC: D1: 360 × 240 (CIF), 720 x 240 (HD1),720 x 480(D1)
960H: 480 × 240 (WCIF), 960 × 240 (WHD1), 960 × 480(WD1)

Record speed:

Recording mode:

Sensor & alarm I/O:

HDD interface:

PTZ control:

Mobile surveillance:

Support mobile phones based on Windows mobile, Symbian, iPhone, blackberry and Android operation system
VGA: 800*600,1024*768,1280*1024,1440*900,1,920*1,080
HDMI: 1,080P
Power supply: DC12V 5A

PAL: 960 × 576 @ 25fps(each ch, frame) NTSC: 960 × 480 @ 30fps (each ch, frame)

Single/Quad/nine/sixteen/S.E.Q

PAL:D1 360 × 288 (CIF),720 x 288 (HD1), 720 x 576(D1) 960H: 480 × 288 (WCIF), 960 × 288 (WHD1), 960 × 576(WD1)

NTSC: D1: 360 × 240 (CIF), 720 x 240 (HD1),720 x 480(D1)

960H: 480 × 240 (WCIF), 960 × 240 (WHD1), 960 × 480(WD1)

PAL: (each ch, frame) D1mode/960Hmode: 25fps(each ch)

NTSC:(each ch, frame) D1mode/960Hmode: 30fps(each ch)

Continuous/manual/motion detect /sensor/alarm recording

Playback channel: 1/4/9ch

8ch sensor input;1 channel alarm out

SATA HDDs, each HDD max up to 4TB

Built in RS485, support Pelco-P & Pelco-D
