Plastic Processing Machine for Bottles with Automatic Break Protection and 0.5MPa Air Pressure

Get Latest Price

Payment Type:: Telegraphic Transfer (TT, T/T)

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Payment Type:	Telegraphic Transfer (TT,T/T)

Product Description

Functions and features:

Automatic break protection for power leakage and short-circuit
Under-pressure protection: when incoming airs pressure is ≤0.5MPa, the equipment will automatically stop
Water-shortage protection: when the level of the water tank is lower than that of the liquid switch, the equipment will automatically stop
Remarks: we can add other functions as per customers' required like hot tank heating washing, bottle external washing, cap washing, capacity note and man-machine control

Main technical standards:

Output: 300BPH
Voltages: 220V AC, 380V ±5%, 50 to 60Hz
Rated power: 8.65kW
Washing heads: 2 x 6
Filling heads: 2 x 2
Capping heads: 2 x 1
Bottle size: Ф270 x 490 x Ф56mm
Cap size: Ф58 x 40mm (tail (L x W) = 18 x 7.5mm)
Air pressure: 0.5 to 0.6MPa
Net weight: 445kg
Overall dimensions: 3,820 x 800 x 1,600mm

Automatic break protection for power leakage and short-circuit

Under-pressure protection: when incoming airs pressure is ≤0.5MPa, the equipment will automatically stop

Water-shortage protection: when the level of the water tank is lower than that of the liquid switch, the equipment will automatically stop

Remarks: we can add other functions as per customers' required like hot tank heating washing, bottle external washing, cap washing, capacity note and man-machine control

Output: 300BPH

Voltages: 220V AC, 380V ±5%, 50 to 60Hz

Rated power: 8.65kW

Washing heads: 2 x 6

Filling heads: 2 x 2

Capping heads: 2 x 1

Bottle size: Ф270 x 490 x Ф56mm

Cap size: Ф58 x 40mm (tail (L x W) = 18 x 7.5mm)

Air pressure: 0.5 to 0.6MPa

Net weight: 445kg

Overall dimensions: 3,820 x 800 x 1,600mm
