Rear View System, 5.6-inch Digital Monitor with Built-in GPS, Wireless Support

Get Latest Price

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Payment Type:	Telegraphic Transfer in Advance (Advance TT, T/T)

Product Description

Monitor specification:

Camera specification:

Screen size: 7 inch digital TFT panel

Rear view monitor support 4 camera inputs

Single/split/quad view selectable

Digital high backlight LCD monitor

With built-in GPS navigation, support wireless

Brightness: 450cdm

Touchscreen: button

9 languages OSD display

PAL/NTSC optional, mirror/normal image optional

Automatically turn on when the reversing gear is engaged

Trigger priority: CAM 1>CAM 2>CAM 3>CAM 4

Built-in speaker (optional)

Heavy-duty reversing

OSD menu

Contrast, color, brightness adjustable

View angle range: (left/right) 65 degrees, (top) 40 degrees, (down) 15 degrees

Type: high resolution backup camera

Image sensor: 1/3" CCD

TV system: NTSC/PAL optional

Effective pixels:

N: 510x492 pixels

P: 500x582 pixels

Horizontal resolution: 420 TV line

Lens angle: 120°

Minimum illumination: 0Lux (LED on)

IR LED 16pcs for night vision distance 45ft

Audio function

Operating temperature and humidity: -20-+70° C, RH 95% maximum

Lens f=2.8mm

Power supply: 12V DC

Net weight: 350g

Water-resistant rate: IP68

Shell material: aluminum alloy
