Power Adapter, Supplier, Manufacturer and Exporter with 1.2 or 1.5m Cable of 12V/2Amp/24W

Get Latest Price

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Payment Type:	T/T, L/C, Western Union, PayPal

Product Description

Voltage: 5/5.5/6/6.5/7/7.5/8/8.5/9/9.5/10/10.5/11/11.5/12/15/16.5/20/21.5/24V

With CE/RoHS/UL/CB/CCC

Power: 2W (maximum)

Delivery time: 7-15 days

Samples are available

Model: JX-C1201000-A

Input voltage: 90-264V AC, 50-60Hz

Rate voltage: 100-240V

Input current: 0.5A (maximum)

Leakage current: <1mA

Output power 12W (maximum)

Output voltage: 12V DC ±5%

Ripple wave (mVp-p): ≤100mV

Linear modulate: ±5% (maximum)

Temperature coefficient: ±0.02%/°C

Start time: ≤3 seconds (100V AC input, full loading)

Guard time: ≥20ms (240V AC input, full loading)

Output standard: 12V/A

Protection override protection: 115-200%VA, automatic recovery

Short-circuit protection:

Insulation strength: 3,000V AC/5mA,1 minute

Insulation resistance: ≥30MΩ, 500V DC

Environment working temperature: 20-90% RH (non-condensing)

Store temperature: 20-90% RH (non-condensing)

Safety standards GB4943-2001 IEC60950

EMC En55022

Efficiency ≥80%

Size (L*W*H): 90*43*33mm

1 channel: automatic recovery
