8V 3A Switching Power Adapter with CE, CB, FCC, UL and CCC Marks
  • 8V 3A Switching Power Adapter with CE, CB, FCC, UL and CCC Marks
  • 8V 3A Switching Power Adapter with CE, CB, FCC, UL and CCC Marks
8V 3A Switching Power Adapter with CE, CB, FCC, UL and CCC Marks
8V 3A Switching Power Adapter with CE, CB, FCC, UL and CCC Marks

8V 3A Switching Power Adapter with CE, CB, FCC, UL and CCC Marks

Get Latest Price
Payment Type:
Telegraphic Transfer in Advance (Advance TT, T/T)
Quantity:

Your message must be between 20 to 2000 characters

Contact Now
Basic Info
Basic Info
Payment Type: Telegraphic Transfer in Advance (Advance TT, T/T)
Product Description
Product Description
  • Specifications:
    • 24W plug in switch power supply
    • Output: 8V/3A/24W
    • High-efficiency, low lose, safe, beautiful
    • With CE, CB, FCC, CCC and UL marks
    • Warranty: 3yrs
  • Features:
    • Input:
      • Input voltage: 90 to 264V AC, 50 to 60Hz
      • Rate voltage: 100 to 240V
      • Input current: 0.5A max
      • Inrush current: ≤20A
      • Leakage current:
      • Output:
        • Output max power: 24W
        • Output voltage: DC 8V ± 5%
        • Ripple wave (mV p-p): ≤100mV
        • Linear modulate: ±5% max
        • Temperature coefficient: ±0.02%/°C
        • Start time: ≤3s (100V AC input, full load)
        • Guard time: ≥20ms (240V AC input, full load)
        • Output standard: 8V/3A
      • Protection:
        • Override protection: 115 to 200%VA, automatic recovery
        • Short-circuit protection: 1 channel, automatic recovery
      • Insulation:
        • Insulation strength: 3000V AC/5mA, 1min
        • Insulation resistance: ≥30MΩ, DC 500V
      • Environment:
        • Working temperature: 0 to 40°C, 20 to 90% RH, non-condensing
        • Store temperature: -20 to 80°C, 20 to 90% RH, non-condensing
      • Standards:
        • Safety standards: GB4943-2001 IEC60950
        • EMC: En55022
      • Efficiency: ≥80%
      • Size (L x W x H): 93.5 x 46.5 x 33mm
      • Packaging: polybag, color box, blister or customized
      • Delivery lead-time: 7 to 12 working days
  • 24W plug in switch power supply
  • Output: 8V/3A/24W
  • High-efficiency, low lose, safe, beautiful
  • With CE, CB, FCC, CCC and UL marks
  • Warranty: 3yrs
  • Input:
    • Input voltage: 90 to 264V AC, 50 to 60Hz
    • Rate voltage: 100 to 240V
    • Input current: 0.5A max
    • Inrush current: ≤20A
    • Leakage current:
    • Output:
      • Output max power: 24W
      • Output voltage: DC 8V ± 5%
      • Ripple wave (mV p-p): ≤100mV
      • Linear modulate: ±5% max
      • Temperature coefficient: ±0.02%/°C
      • Start time: ≤3s (100V AC input, full load)
      • Guard time: ≥20ms (240V AC input, full load)
      • Output standard: 8V/3A
    • Protection:
      • Override protection: 115 to 200%VA, automatic recovery
      • Short-circuit protection: 1 channel, automatic recovery
    • Insulation:
      • Insulation strength: 3000V AC/5mA, 1min
      • Insulation resistance: ≥30MΩ, DC 500V
    • Environment:
      • Working temperature: 0 to 40°C, 20 to 90% RH, non-condensing
      • Store temperature: -20 to 80°C, 20 to 90% RH, non-condensing
    • Standards:
      • Safety standards: GB4943-2001 IEC60950
      • EMC: En55022
    • Efficiency: ≥80%
    • Size (L x W x H): 93.5 x 46.5 x 33mm
    • Packaging: polybag, color box, blister or customized
    • Delivery lead-time: 7 to 12 working days
  • Input voltage: 90 to 264V AC, 50 to 60Hz
  • Rate voltage: 100 to 240V
  • Input current: 0.5A max
  • Inrush current: ≤20A
  • Leakage current:
  • Output:
    • Output max power: 24W
    • Output voltage: DC 8V ± 5%
    • Ripple wave (mV p-p): ≤100mV
    • Linear modulate: ±5% max
    • Temperature coefficient: ±0.02%/°C
    • Start time: ≤3s (100V AC input, full load)
    • Guard time: ≥20ms (240V AC input, full load)
    • Output standard: 8V/3A
  • Protection:
    • Override protection: 115 to 200%VA, automatic recovery
    • Short-circuit protection: 1 channel, automatic recovery
  • Insulation:
    • Insulation strength: 3000V AC/5mA, 1min
    • Insulation resistance: ≥30MΩ, DC 500V
  • Environment:
    • Working temperature: 0 to 40°C, 20 to 90% RH, non-condensing
    • Store temperature: -20 to 80°C, 20 to 90% RH, non-condensing
  • Standards:
    • Safety standards: GB4943-2001 IEC60950
    • EMC: En55022
  • Efficiency: ≥80%
  • Size (L x W x H): 93.5 x 46.5 x 33mm
  • Packaging: polybag, color box, blister or customized
  • Delivery lead-time: 7 to 12 working days
  • Output max power: 24W
  • Output voltage: DC 8V ± 5%
  • Ripple wave (mV p-p): ≤100mV
  • Linear modulate: ±5% max
  • Temperature coefficient: ±0.02%/°C
  • Start time: ≤3s (100V AC input, full load)
  • Guard time: ≥20ms (240V AC input, full load)
  • Output standard: 8V/3A
  • Override protection: 115 to 200%VA, automatic recovery
  • Short-circuit protection: 1 channel, automatic recovery
  • Insulation strength: 3000V AC/5mA, 1min
  • Insulation resistance: ≥30MΩ, DC 500V
  • Working temperature: 0 to 40°C, 20 to 90% RH, non-condensing
  • Store temperature: -20 to 80°C, 20 to 90% RH, non-condensing
  • Safety standards: GB4943-2001 IEC60950
  • EMC: En55022
