Crystal Resonator, 12,000MHz Frequency, 3225 SMD, 3.2 x 2.5mm

Get Latest Price

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Payment Type:	Telegraphic Transfer (TT,T/T)

Product Description

Features:

Specifications:

Packing:

Ultra thin, thickness 1.0mm

Lead less type

High precision characteristic covering up to high frequencyrange

Designed for automatic mounting and re flow soldering

Emboss taping specification

Frequency: 12,000MHz

Equivalent series resistance (ESR): 80/60©

Frequency tolerance (at 25°C): ±10, ±30ppm orspecify

Frequency stability: ±10, ±30ppm or specify

Operating temperature range: -10 to +60, -20 to +70, -40 to+85°C

Storage temperature range: -55 to +125°C

Shunt capacitance: 5pF (maximum)

Drive level: 100¼W

Load capacitance: series, 16, 20, 30, 32pF or specify

Certificates: RoHS, PB free, SGS and more

Sealed ceramic surface mount

Aging: ±3ppm/Year

Seam sealed ceramic 3.2 x 2.5mm surface mount packing
