2.0 x 1.6mm Crystal Unit, Seam Sealed Ceramic, Surface Mount Package, Ultra-size, Pb Free Compliant
  • 2.0 x 1.6mm Crystal Unit, Seam Sealed Ceramic, Surface Mount Package, Ultra-size, Pb Free Compliant
2.0 x 1.6mm Crystal Unit, Seam Sealed Ceramic, Surface Mount Package, Ultra-size, Pb Free Compliant

2.0 x 1.6mm Crystal Unit, Seam Sealed Ceramic, Surface Mount Package, Ultra-size, Pb Free Compliant

Get Latest Price
Payment Type:
Telegraphic Transfer (TT, T/T)
Quantity:

Your message must be between 20 to 2000 characters

Contact Now
Basic Info
Basic Info
Payment Type: Telegraphic Transfer (TT,T/T)
Product Description
Product Description
  • Features:
    • High precision and high frequency stability
    • Excellent heat resistance and environmentalcharacteristics
    • Ultra-size
    • RoHS and Pb free compliant
    • Seam sealed ceramic 2.0 x 1.6mm surface mount package
  • Electrical specifications:
    • Output frequency range: 20.000 to 54.000MHz
    • Frequency tolerance (at 25°c): ±10 to ±30ppm(specify)
    • Frequency stability over operating temperature: ±10 to±30ppm (specify)
    • Storage temperature range: -55 to +125°C
    • Operating temperature range: -10 to +60, -20 to +70 and -40 to+85°C
    • Shunt capacity: 3.0pF (maximum)
    • Driver level: 10 to 100¼w
    • Load capacitance: 12, 16, 20, 30 and 32pF or specify
    • Aging (at 25°C): ±3ppm/year
    • Shock resistance: drop test of 3 times on 2mm stainless platefrom 75cm height
  • Applications: Pads, DVCs, PCs, mobile phones, smart devices,MID, Bluetooth, NFC devices and more electronic products
  • High precision and high frequency stability
  • Excellent heat resistance and environmentalcharacteristics
  • Ultra-size
  • RoHS and Pb free compliant
  • Seam sealed ceramic 2.0 x 1.6mm surface mount package
  • Output frequency range: 20.000 to 54.000MHz
  • Frequency tolerance (at 25°c): ±10 to ±30ppm(specify)
  • Frequency stability over operating temperature: ±10 to±30ppm (specify)
  • Storage temperature range: -55 to +125°C
  • Operating temperature range: -10 to +60, -20 to +70 and -40 to+85°C
  • Shunt capacity: 3.0pF (maximum)
  • Driver level: 10 to 100¼w
  • Load capacitance: 12, 16, 20, 30 and 32pF or specify
  • Aging (at 25°C): ±3ppm/year
  • Shock resistance: drop test of 3 times on 2mm stainless platefrom 75cm height
