Power Triode, Used Thoriated Tungsten Filament
  • Power Triode, Used Thoriated Tungsten Filament
Power Triode, Used Thoriated Tungsten Filament

Power Triode, Used Thoriated Tungsten Filament

Get Latest Price
Payment Type:
T/T
Quantity:

Your message must be between 20 to 2000 characters

Contact Now
Basic Info
Basic Info
Payment Type: T/T
Product Description
Product Description
  • Specifications:
    • 608J2F power triode
    • 608J2F is a water cooled, metal/ceramic power triode
    • It uses a thoriated tungsten filament
    • Power triode BW1, 608J2F is a water cooled, metal and ceramicpower triode
    • It uses a thoriated tungsten filament and a coaxial structure,intended for use in industrial radio frequency heating asoscillator
    • Maximum frequency: 30MHz
    • Maximum plate dissipation: 50kW
    • Output power (class C oscillator, less driver): 118kW
  • General characteristics:
    • Filament voltage: 2V
    • Filament current: 178A
    • Filament surge current: 890A maximum
    • Filament cold resistance: 8.0 m©
  • Interelectrode capacitance:
    • Grid-anode: 47pF
    • Grid-cathode: 126pF
    • Anode-cathode: 2.0pF
    • Amplification factor: 40
    • Transconductance (Va = 10kV, Ia = 4A): 80mA/V
    • Operating position vertical, anode up or down
    • Net weight: 12kg
  • 608J2F power triode
  • 608J2F is a water cooled, metal/ceramic power triode
  • It uses a thoriated tungsten filament
  • Power triode BW1, 608J2F is a water cooled, metal and ceramicpower triode
  • It uses a thoriated tungsten filament and a coaxial structure,intended for use in industrial radio frequency heating asoscillator
  • Maximum frequency: 30MHz
  • Maximum plate dissipation: 50kW
  • Output power (class C oscillator, less driver): 118kW
  • Filament voltage: 2V
  • Filament current: 178A
  • Filament surge current: 890A maximum
  • Filament cold resistance: 8.0 m©
  • Grid-anode: 47pF
  • Grid-cathode: 126pF
  • Anode-cathode: 2.0pF
  • Amplification factor: 40
  • Transconductance (Va = 10kV, Ia = 4A): 80mA/V
  • Operating position vertical, anode up or down
  • Net weight: 12kg
