30W LED Power Supply
  • 30W LED Power Supply
30W LED Power Supply

30W LED Power Supply

Get Latest Price
Payment Type:
T/T
Quantity:

Your message must be between 20 to 2000 characters

Contact Now
Basic Info
Basic Info
Payment Type: T/T
Product Description
Product Description
  • Electrical characteristics:
    • Input voltage: 100 to 240V AC
    • Input current: 0.8A (maximum)
    • Frequency: 50/60Hz (47 to 63Hz)
    • Output voltage: 25 ±1V
    • Output current: 1.1 to 1.4A
    • Transfer efficiency: 85%
    • Ripples and noises: 3V (maximum)
    • Line regulation: ±3%
    • Load regulation: ±5%
    • Short-circuit protection
    • Reliability
    • Hi-pot test: 3000V AC
    • Insulation resistance: 10M© (minimum)
    • Leakage current: 0.25mA (maximum)
    • Operating temperature: -10 to +50°C
    • Storage humidity: 10 to 90% RH
    • MTBF: 100,000 hours
    • Size: 70 to 33mm
  • Input voltage: 100 to 240V AC
  • Input current: 0.8A (maximum)
  • Frequency: 50/60Hz (47 to 63Hz)
  • Output voltage: 25 ±1V
  • Output current: 1.1 to 1.4A
  • Transfer efficiency: 85%
  • Ripples and noises: 3V (maximum)
  • Line regulation: ±3%
  • Load regulation: ±5%
  • Short-circuit protection
  • Reliability
  • Hi-pot test: 3000V AC
  • Insulation resistance: 10M© (minimum)
  • Leakage current: 0.25mA (maximum)
  • Operating temperature: -10 to +50°C
  • Storage humidity: 10 to 90% RH
  • MTBF: 100,000 hours
  • Size: 70 to 33mm
