30/60W Single-port POE Injector with CE, FCC and RoHS Approvals

Get Latest Price

Payment Type:: Telegraphic Transfer (TT, T/T)

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Payment Type:	Telegraphic Transfer (TT,T/T)

Product Description

Power supply adapted to indoor using

Input voltage: 90 to 280V AC

Can work over Cat5 cable connection between power supply and network terminal equipment with an Ethernet data port, a output port of synthesis of data and power

The device can be connected to Ethernet devices, such as routers, switches, wireless AP, telephone network, industrial network terminals, network cameras and other POE powered applications consistent with IEEE802.3af/at of international standard

Meets needs of remote place without power or through Ethernet cable to power supply

To increase reliability and simplify of system installation for equipment, provide efficient engineering solutions

Product description:

Single-port output 60W, 10/100/1,000Mbps, 8 lines all powered Single-port output 30W, 10/100/1,000Mbps, supply power by data cable

Key features:

Power with function of entered under-voltage, output over-voltage, each output flow and short-circuit protections
System reliability: MTBF> 100k hours
Conducted interference (CE) and radiation interference (RE), in line with EN55022, class B standard
Lightning features: AC input, able to withstand 5KB, 8/20uS impact of current waveform, plus or minus five times at intervals of one minute
Power supply lightning protection circuit has failure alarm function and fuse safety protection devices
Per port: link, speed, PoE active and error
Working temperature: 0 to 40°C
Storage temperature: -10 to 70°C
Operating humidity: 20 to 85% RH, non-condensing
LED indicator system: power, PoE maximum 110W
Installation and management: Plug-and-play Midspan automatically detect all devices support for PoE
Warranty: one year

Single-port output 60W, 10/100/1,000Mbps, 8 lines all powered Single-port output 30W, 10/100/1,000Mbps, supply power by data cable

Power with function of entered under-voltage, output over-voltage, each output flow and short-circuit protections

System reliability: MTBF> 100k hours

Conducted interference (CE) and radiation interference (RE), in line with EN55022, class B standard

Lightning features: AC input, able to withstand 5KB, 8/20uS impact of current waveform, plus or minus five times at intervals of one minute

Power supply lightning protection circuit has failure alarm function and fuse safety protection devices

Per port: link, speed, PoE active and error

Working temperature: 0 to 40°C

Storage temperature: -10 to 70°C

Operating humidity: 20 to 85% RH, non-condensing

LED indicator system: power, PoE maximum 110W

Installation and management: Plug-and-play Midspan automatically detect all devices support for PoE

Warranty: one year
