Waterproof 12V 2.5A 30W Constant Voltage LED Driver IP67New
  • Waterproof 12V 2.5A 30W Constant Voltage LED Driver IP67New
  • Waterproof 12V 2.5A 30W Constant Voltage LED Driver IP67New
  • Waterproof 12V 2.5A 30W Constant Voltage LED Driver IP67New
  • Waterproof 12V 2.5A 30W Constant Voltage LED Driver IP67New
  • Waterproof 12V 2.5A 30W Constant Voltage LED Driver IP67New
  • Waterproof 12V 2.5A 30W Constant Voltage LED Driver IP67New
Waterproof 12V 2.5A 30W Constant Voltage LED Driver IP67New
Waterproof 12V 2.5A 30W Constant Voltage LED Driver IP67New
Waterproof 12V 2.5A 30W Constant Voltage LED Driver IP67New
Waterproof 12V 2.5A 30W Constant Voltage LED Driver IP67New
Waterproof 12V 2.5A 30W Constant Voltage LED Driver IP67New
Waterproof 12V 2.5A 30W Constant Voltage LED Driver IP67New

Waterproof 12V 2.5A 30W Constant Voltage LED Driver IP67New

Get Latest Price
Payment Type:
T/T
Quantity:

Your message must be between 20 to 2000 characters

Contact Now
Basic Info
Basic Info
Payment Type: T/T
Product Description
Product Description
  • Features:
    • Universal AC input
    • High efficiency and high reliability
    • Protections: SCP, OVP, OLP
    • Passed UL, CUL, FCC, GS, CE, CCC certifications
    • 100% full load burn-in test
    • MBTF ≥30.000hrs (25°C, full load)
  • Applications:
    • CD/DVD, MP3/MP4, digital camera
    • Communication terminals
  • Input:
    • Voltage range: 100 to 240V AC
    • Frequency range: 50-60Hz
    • Leakage current:
      • Primary-secondary:<0.25Ma
  • Output:
    • Hold up time: >10Ms (115V AC input, full load), <20ms(230V AC input, full load)
    • Set up time: <3.0S (115V AC input, full load), 1.5s (230V AC input, full load)
    • Load regulation: ±5%
    • Line regulation: ±2%
  • Protection:
    • Short circuit: no damage for short-circuit, auto recovery
  • Environment:
    • Operating ambient temperature and humidity: -0 to 40°C/5-95% RH
    • Storage temperature humidity: -20 to 85°C/5-95% RH
  • Safety and EMC:
    • Withstand voltage:
      • Input-output: 3.0kV AC, 1min (≦5mA)
    • Isolation resistance: ≥100MΩ at DC 500V
    • EMI conduction and radiation: compliant to EN55022 (CISPR22) Class B, FCC Part15, GB9254-2008
    • EMS immunity: compliant to EN61000-4-0, 3, 4, 5, 6, 8, 11
    • Safety standards: UL60950-1, GB4943-2001, EN60950-1:2006
  • Universal AC input
  • High efficiency and high reliability
  • Protections: SCP, OVP, OLP
  • Passed UL, CUL, FCC, GS, CE, CCC certifications
  • 100% full load burn-in test
  • MBTF ≥30.000hrs (25°C, full load)
  • CD/DVD, MP3/MP4, digital camera
  • Communication terminals
  • Voltage range: 100 to 240V AC
  • Frequency range: 50-60Hz
  • Leakage current:
    • Primary-secondary:<0.25Ma
  • Primary-secondary:<0.25Ma
  • Hold up time: >10Ms (115V AC input, full load), <20ms(230V AC input, full load)
  • Set up time: <3.0S (115V AC input, full load), 1.5s (230V AC input, full load)
  • Load regulation: ±5%
  • Line regulation: ±2%
  • Short circuit: no damage for short-circuit, auto recovery
  • Operating ambient temperature and humidity: -0 to 40°C/5-95% RH
  • Storage temperature humidity: -20 to 85°C/5-95% RH
  • Withstand voltage:
    • Input-output: 3.0kV AC, 1min (≦5mA)
  • Isolation resistance: ≥100MΩ at DC 500V
  • EMI conduction and radiation: compliant to EN55022 (CISPR22) Class B, FCC Part15, GB9254-2008
  • EMS immunity: compliant to EN61000-4-0, 3, 4, 5, 6, 8, 11
  • Safety standards: UL60950-1, GB4943-2001, EN60950-1:2006
  • Input-output: 3.0kV AC, 1min (≦5mA)
