Compression Load Cell, Stainless Steel

Get Latest Price

Payment Type:: T/T in Advance, PayPal, Western Union

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Payment Type:	T/T in Advance, PayPal, Western Union

Product Description

Features:

Stainless steel material with oil-proof and waterproof, anti-corrosion, can be worked in all types of environment
Diaphragm capsule structure, compression bearing and easy to install
Mainly applied in force measurement in small space installation, such as feeling tester for keyboard switch, compression measurement for hot and cold lamination machine and grasping force measurement for robotic hands

Capacity: 50N to 120KN

Specifications:

Rated output: 2.0mV/V ±10%
Zero balance: ±2%FS
Non-linearity: 0.5%FS
Hysteresis: 0.5%FS
Repeatability: 0.5%FS
Creep (30 minutes): 0.5%FS
Temperature effect on output: 0.5%FS/10°C
Temperature effect on zero: 0.5%FS/10°C
Input impedance: 350 ±5Ω
Output impedance: 350 ±5Ω
Insulation: ≥5000MΩ/100V DC
Recommended excitation: 5 to 10V
Maximum excitation: 15V
Compensated temperature range: -10 to 60°C
Operating temperature range: -20 to 80°C
Safe overload: 120%
Ultimate overload: 150%
Cable size: Ø3 (4) x 2m

Wire connection:

Ex+: red
Ex-: black
Output+: green
Output -: white
