Terminal Block, R/A Pitch 5.0/5.08/7.5/7.62mm Wire Range, 24-12AWG Poles, 2P/3P 300V/25A 0911
  • Terminal Block, R/A Pitch 5.0/5.08/7.5/7.62mm Wire Range, 24-12AWG Poles, 2P/3P 300V/25A 0911
Terminal Block, R/A Pitch 5.0/5.08/7.5/7.62mm Wire Range, 24-12AWG Poles, 2P/3P 300V/25A 0911

Terminal Block, R/A Pitch 5.0/5.08/7.5/7.62mm Wire Range, 24-12AWG Poles, 2P/3P 300V/25A 0911

Get Latest Price
Payment Type:
T/T or PayPal
Quantity:

Your message must be between 20 to 2000 characters

Contact Now
Basic Info
Basic Info
Payment Type: T/T or PayPal
Product Description
Product Description
  • Pitch: 5.0/5.08/7.5/7.62mm
  • Poles: 2P, 3P
  • Screws: M3/steel/zinc plated
  • Wire cage: steel zinc plated or brass Ni plated
  • Pin header: brass tin plated
  • Housing: PA66.UL94V-0
  • Rated voltage: 300V
  • Rated current: 25A
  • Withstanding voltage: 2,000V AC/1 minute
  • Wire range: 24-12AWG
  • Temperature range: -40-105°C
  • Maximum soldering: 250°C for 5 seconds
  • Torque: 0.5Nm (4.4lb.in)
  • Strip length: 6-7mm
