P10 Outdoor RGB LED Display Screen, Black Powder-coated Steel Material

Get Latest Price

Payment Type:: T/T or Western Union

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Payment Type:	T/T or Western Union

Product Description

LED lamp:

LED lamps: DIP346 oval
Wavelength:
- Red LED: 620 to 630nm
- Green LED: 520 to 535nm
- Blue LED: 465 to 475nm

LED module:

Pixel pitch: 10mm
Pixel configuration: 1R1G1B
Module resolution: 16 x 16 dots
Module size: 160 x 160mm

LED cabinet (standard cabinet):

Cabinet size: 960 x 960mm
Cabinet resolution: 96 x 96 pixels dots
Module quantity: 36 pieces
Cabinet frame material: black powder-coated steel
Cabinet weight: 55kg

Screen:

Screen resolution: 10,000 dots/m²
Screen brightness: 8,000 nits
Brightness adjustment: manually or automatically
Driving method: constant current 1/4
Viewing angle (H x V): 110 x 60°
Optimum viewing distance: 5 to 200m
Refreshing frequency: 1,500Hz (adjustable by software)
Input voltage: 220V AC/50Hz or 110V AC/60Hz
Power consumption maximum: 1,200W/m²
Average: 400 to 8,00W/m²
Defects rate: ≤0.00001
MTBF: >5,000 hours
Lifespan: ≥100,000 hours
Protection grade: IP65
Operating temperature: -40 to 60°C
Humidity: 10 to 95%
Operating systems: Microsoft's Windows 98/Me/2000/NT/XP

LED lamps: DIP346 oval

Wavelength:

Red LED: 620 to 630nm
Green LED: 520 to 535nm
Blue LED: 465 to 475nm

Red LED: 620 to 630nm

Green LED: 520 to 535nm

Blue LED: 465 to 475nm

Pixel pitch: 10mm

Pixel configuration: 1R1G1B

Module resolution: 16 x 16 dots

Module size: 160 x 160mm

Cabinet size: 960 x 960mm

Cabinet resolution: 96 x 96 pixels dots

Module quantity: 36 pieces

Cabinet frame material: black powder-coated steel

Cabinet weight: 55kg

Screen resolution: 10,000 dots/m²

Screen brightness: 8,000 nits

Brightness adjustment: manually or automatically

Driving method: constant current 1/4

Viewing angle (H x V): 110 x 60°

Optimum viewing distance: 5 to 200m

Refreshing frequency: 1,500Hz (adjustable by software)

Input voltage: 220V AC/50Hz or 110V AC/60Hz

Power consumption maximum: 1,200W/m²

Average: 400 to 8,00W/m²

Defects rate: ≤0.00001

MTBF: >5,000 hours

Lifespan: ≥100,000 hours

Protection grade: IP65

Operating temperature: -40 to 60°C

Humidity: 10 to 95%

Operating systems: Microsoft's Windows 98/Me/2000/NT/XP
