120W Power Adapter, Lightweight, Compact

120W Power Adapter, Lightweight, Compact

Get Latest Price

Payment Type:: Telegraphic Transfer in Advance (Advance TT, T/T)

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Payment Type:	Telegraphic Transfer in Advance (Advance TT, T/T)

Product Description

120W power adapter (desktop)

Lightweight, compact design

RoHS power supply, fully conform to the requirements of the energy star

High power density

Super safe design, perfect protection function

Scope of applications:

Mobile device
LED lighting products
Audio and video products
POS machine
Security equipment
Household appliances

Green mode:

Meet CEC regulations and RoHS compliance
No load power consumption less than 0.1w

Reliability:

The average time between failures
At 25℃ ambient temperature, the maximum working load

The average time between failures, 5,000 hours

The input:

The input voltages: 90V~264V AC
Frequency range: 47~50/60~63Hz
Input current: 2.0A (max) 100/240VAC
Surge current: AT 100V AC 30A Max at 240V AC 60A Max
Leakage current: 0.25mA Max

Output:

Over voltage protection
Over current protection: 110 ~ 200% rated load, have the function of automatic recovery
Short circuit protection

Working temperatures: 0-40℃

Storage temperatures: 20-60 ℃

Humidity enrichment conditions, humidity 5% to 95%

Product list: JP120-XXXYYYY

Voltages (VV): 5.0-8.9/18.0-24.0/9.0-13.5/13.6-17.9V
Current (amps): 0-10.0/0-7.50/0-7.00/0-5.60A
Power (W ): 50W Max/90W
100W maximum/120W maximum
Ripple wave: 100mVp-p
Efficiency: 80/85%

Electromagnetic interference:

Conduction, radiation test: CE: EN55022:2010 FCC: Part 15
Harmonic testing: EN 61000-3-2:2006+A2:2009
Voltage change test: EN 61000-3-3:2008

Electromagnetic compatibility:

Static test: EN61000-4-2
Radiation tolerance test: EN61000-4-3
Electronic rapid pulse test: EN61000-4-4
Lightning test: EN61000-4-5
The conduction resistance test: EN61000-4-6
Voltage dip test: EN61000-4-11

UL standards

EN60950-1

UL60950-1

UL certification

CB TUV/GS UL/CUL KC SAA PSE

CE FCC C-TICK

Mobile device

LED lighting products

Audio and video products

POS machine

Security equipment

Household appliances

Meet CEC regulations and RoHS compliance

No load power consumption less than 0.1w

The average time between failures

At 25℃ ambient temperature, the maximum working load

The input voltages: 90V~264V AC

Frequency range: 47~50/60~63Hz

Input current: 2.0A (max) 100/240VAC

Surge current: AT 100V AC 30A Max at 240V AC 60A Max

Leakage current: 0.25mA Max

Over voltage protection

Over current protection: 110 ~ 200% rated load, have the function of automatic recovery

Short circuit protection

Voltages (VV): 5.0-8.9/18.0-24.0/9.0-13.5/13.6-17.9V

Current (amps): 0-10.0/0-7.50/0-7.00/0-5.60A

Power (W ): 50W Max/90W
100W maximum/120W maximum

Ripple wave: 100mVp-p

Efficiency: 80/85%

Conduction, radiation test: CE: EN55022:2010 FCC: Part 15

Harmonic testing: EN 61000-3-2:2006+A2:2009

Voltage change test: EN 61000-3-3:2008

Static test: EN61000-4-2

Radiation tolerance test: EN61000-4-3

Electronic rapid pulse test: EN61000-4-4

Lightning test: EN61000-4-5

The conduction resistance test: EN61000-4-6

Voltage dip test: EN61000-4-11
