LV1000 1D OEM CCD Barcode Scanner Bluetooth Module, Easy Integration into Kiosk, PC and PDA
  • LV1000 1D OEM CCD Barcode Scanner Bluetooth Module, Easy Integration into Kiosk, PC and PDA
  • LV1000 1D OEM CCD Barcode Scanner Bluetooth Module, Easy Integration into Kiosk, PC and PDA
  • LV1000 1D OEM CCD Barcode Scanner Bluetooth Module, Easy Integration into Kiosk, PC and PDA
  • LV1000 1D OEM CCD Barcode Scanner Bluetooth Module, Easy Integration into Kiosk, PC and PDA
  • LV1000 1D OEM CCD Barcode Scanner Bluetooth Module, Easy Integration into Kiosk, PC and PDA
  • LV1000 1D OEM CCD Barcode Scanner Bluetooth Module, Easy Integration into Kiosk, PC and PDA
  • LV1000 1D OEM CCD Barcode Scanner Bluetooth Module, Easy Integration into Kiosk, PC and PDA
  • LV1000 1D OEM CCD Barcode Scanner Bluetooth Module, Easy Integration into Kiosk, PC and PDA
LV1000 1D OEM CCD Barcode Scanner Bluetooth Module, Easy Integration into Kiosk, PC and PDA
LV1000 1D OEM CCD Barcode Scanner Bluetooth Module, Easy Integration into Kiosk, PC and PDA
LV1000 1D OEM CCD Barcode Scanner Bluetooth Module, Easy Integration into Kiosk, PC and PDA
LV1000 1D OEM CCD Barcode Scanner Bluetooth Module, Easy Integration into Kiosk, PC and PDA
LV1000 1D OEM CCD Barcode Scanner Bluetooth Module, Easy Integration into Kiosk, PC and PDA
LV1000 1D OEM CCD Barcode Scanner Bluetooth Module, Easy Integration into Kiosk, PC and PDA
LV1000 1D OEM CCD Barcode Scanner Bluetooth Module, Easy Integration into Kiosk, PC and PDA
LV1000 1D OEM CCD Barcode Scanner Bluetooth Module, Easy Integration into Kiosk, PC and PDA

LV1000 1D OEM CCD Barcode Scanner Bluetooth Module, Easy Integration into Kiosk, PC and PDA

Get Latest Price
Payment Type:
Telegraphic Transfer (TT, T/T)
Quantity:

Your message must be between 20 to 2000 characters

Contact Now
Basic Info
Basic Info
Payment Type: Telegraphic Transfer (TT,T/T)
Product Description
Product Description
  • Introduction:
    • Can develop special and small size
    • 3.3-5V medical industry PC kiosk
    • Topside has electrical control components, including flexible cable socket, interface socket, through which LV1000 interfaces with external device
    • Front side has optical components such as image lens, through which LV1000 captures image
    • Aiming light, which sends rectangular, green light beam for aiming and illumination lights, which illuminates barcode
    • Bracket covers sides and bottom of engine
    • Two mounting holes on the bottom side are available for mounting engine to external device
    • Back side is CCD circuit for image capture
  • Specifications:
    • Interface: TTL232
    • Image sensor: CCD
    • Scan rate: up to 200 scans/second
    • Light source: LED (622-628nm)
    • Depth of scan field: 40-430mm
    • Illumination: 0-100,000lux
    • Power consumption: 0.33W
    • Voltage: 3.3V DC
    • Current working: 150mA (maximum)
    • Idle: 45mA
    • Sleep: 1mA
    • Weight: 6g
    • Dimensions: 28*23*11mm
  • Can develop special and small size
  • 3.3-5V medical industry PC kiosk
  • Topside has electrical control components, including flexible cable socket, interface socket, through which LV1000 interfaces with external device
  • Front side has optical components such as image lens, through which LV1000 captures image
  • Aiming light, which sends rectangular, green light beam for aiming and illumination lights, which illuminates barcode
  • Bracket covers sides and bottom of engine
  • Two mounting holes on the bottom side are available for mounting engine to external device
  • Back side is CCD circuit for image capture
  • Interface: TTL232
  • Image sensor: CCD
  • Scan rate: up to 200 scans/second
  • Light source: LED (622-628nm)
  • Depth of scan field: 40-430mm
  • Illumination: 0-100,000lux
  • Power consumption: 0.33W
  • Voltage: 3.3V DC
  • Current working: 150mA (maximum)
  • Idle: 45mA
  • Sleep: 1mA
  • Weight: 6g
  • Dimensions: 28*23*11mm
