Product Description

Solar on-grid system: solar panel + grid tie inverter

Solar off-grid system: solar panel + hybrid inverter (controller, inverter) + battery

System applications:

Living house and home building
Office building, factory and warehouse
Shopping mall, venue, stadium and more
Power station, field operation and some huge engineer construction

Features:

Solar panel (mono or poly panel) 36pcs*200W
- Vmp: 34.4V
- Voc: 43.2V
- Imp: 5.2A
- Weight: 15kg
- Size: 1610*670*35mm
- 25-year power output guarantee
PV array combiner
- H10T-96V multiple PV strings inputs
- Simplify wiring between PV array and controller, protections to controller, features: wide range of DC input voltage, reliable thunderstorm and surge protection
Hybrid inverter built-in solar controller
- Inverter power: 8kW/96V
- MPPT controller model: 96V/100A
- Charging efficiency: 90-95%
- LCD display inverter and controller info with AC charger built-in
- Output: 110, 120, 220, 230, 240V (optional)
- Product size: 590*470*730mm
- Weight: 91kg
Battery (lead or gel battery)
- Capacity: 12V/200Ah fully sealed*24pcs
- Solar power lead-acid battery
- Service lifespan: 5-6 years
- Size: 522*238*218mm
- Weight: 58kg
- Connecting way: 8pcs panels in series as a string, 3 strings in parallel
Solar panel rack (ground or roof type)
- Ground rack installation including complete fittings (other types of rack can be customized as per client's requirements, picture in last page)
Cable
- 10mm² cables (one red and one black)
- International standard, with specification suitable for solar system

Remarks:

Living house and home building

Office building, factory and warehouse

Shopping mall, venue, stadium and more

Power station, field operation and some huge engineer construction

Solar panel (mono or poly panel) 36pcs*200W

Vmp: 34.4V
Voc: 43.2V
Imp: 5.2A
Weight: 15kg
Size: 1610*670*35mm
25-year power output guarantee

PV array combiner

H10T-96V multiple PV strings inputs
Simplify wiring between PV array and controller, protections to controller, features: wide range of DC input voltage, reliable thunderstorm and surge protection

Hybrid inverter built-in solar controller

Inverter power: 8kW/96V
MPPT controller model: 96V/100A
Charging efficiency: 90-95%
LCD display inverter and controller info with AC charger built-in
Output: 110, 120, 220, 230, 240V (optional)
Product size: 590*470*730mm
Weight: 91kg

Battery (lead or gel battery)

Capacity: 12V/200Ah fully sealed*24pcs
Solar power lead-acid battery
Service lifespan: 5-6 years
Size: 522*238*218mm
Weight: 58kg
Connecting way: 8pcs panels in series as a string, 3 strings in parallel

Solar panel rack (ground or roof type)

Ground rack installation including complete fittings (other types of rack can be customized as per client's requirements, picture in last page)

Cable

10mm² cables (one red and one black)
International standard, with specification suitable for solar system

Vmp: 34.4V

Voc: 43.2V

Imp: 5.2A

Weight: 15kg

Size: 1610*670*35mm

25-year power output guarantee

H10T-96V multiple PV strings inputs

Simplify wiring between PV array and controller, protections to controller, features: wide range of DC input voltage, reliable thunderstorm and surge protection

Inverter power: 8kW/96V

MPPT controller model: 96V/100A

Charging efficiency: 90-95%

LCD display inverter and controller info with AC charger built-in

Output: 110, 120, 220, 230, 240V (optional)

Product size: 590*470*730mm

Weight: 91kg

Capacity: 12V/200Ah fully sealed*24pcs

Solar power lead-acid battery

Service lifespan: 5-6 years

Size: 522*238*218mm

Weight: 58kg
