Gigabit 10/100/1,000M RJ-45 Fiber-optic Media Converters
  • Gigabit 10/100/1,000M RJ-45 Fiber-optic Media Converters
Gigabit 10/100/1,000M RJ-45 Fiber-optic Media Converters

Gigabit 10/100/1,000M RJ-45 Fiber-optic Media Converters

Get Latest Price
Payment Type:
T/T or L/C at Sight
Quantity:

Your message must be between 20 to 2000 characters

Contact Now
Basic Info
Basic Info
Payment Type: T/T or L/C at Sight
Product Description
Product Description
  • Main features:
    • Transmission of a channel signals can be completed by single fiber
    • It has doubled in quantity of fiber data transmission compared with twin fiber
    • Auto negotiation function allows UTP ports to auto select 10/100/1,000M and full or half duplex
    • The UTP port supports the connection of MDI/MDI-X auto-crossover
    • Multi-mode fiber: the max distance up to 224/550m
    • Single mode fiber: the max distance up to 100km
    • Supports maximum 1,536 byte Ethernet packet
    • Supports flow control
    • Adopts internal power supply
  • Technical specifications:
    • Operating standards:
      • IEEE802.3 10Base-T Ethernet
      • IEEE802.3u 100Base-TX/FX fast Ethernet
      • IEEE802.3ab 1,000Base-T
      • IEEE802.3z 1,000Base-SX/LX Gigabit
    • Wavelength: 850/1,310/1,550nm
    • MAC address table: 4K
    • Data buffer: 256K
    • Connector:
      • UTP: RJ-45, 10/100/1,000Mbps
      • Fiber: SC, 1,000Mbps
    • Cable:
      • UTP cable: Cat 5e or Cat 6 (maximum distance up to 100m)
      • Fiber:
        Multi-mode: 50/125, 62.5/125μm (maximum distance up to 550/224m)
      • Single mode: 8.3/125, 8.7/125, 9/125μm (maximum distance up to 120km)
      • Connector: FC/PC or SC or SFP port
    • Flow control:
      • Full duplex: IEEE802.3x
      • Half duplex: back pressure
    • Conversion mode: medium conversion
    • MTBF: 80,000 hours
    • LED:
      • FX LINK (fiber link action)
      • TP LINK1000 (twisted pair connection 1,000M)
      • TP LINK100 (twisted pair connection 100M)
      • TP ACT (twisted pair packet forwarding action)
      • FDX (Ethernet interface mode indicator on, full duplex/off, half duplex)
  • Power requirements:
    • Input range: AC 170-240V or DC 36-72V
    • Output: DC 5V 2A
    • Power consumption: 5W
    • Ambient temperatures: 0 to +50
    • Storage temperatures: -20 to +70
    • Humidity range: 5 to 90%
  • Dimensions:
    • Internal power: 30 × 110 × 140mm
    • External power: 26 × 70 × 93mm
  • Transmission of a channel signals can be completed by single fiber
  • It has doubled in quantity of fiber data transmission compared with twin fiber
  • Auto negotiation function allows UTP ports to auto select 10/100/1,000M and full or half duplex
  • The UTP port supports the connection of MDI/MDI-X auto-crossover
  • Multi-mode fiber: the max distance up to 224/550m
  • Single mode fiber: the max distance up to 100km
  • Supports maximum 1,536 byte Ethernet packet
  • Supports flow control
  • Adopts internal power supply
  • Operating standards:
    • IEEE802.3 10Base-T Ethernet
    • IEEE802.3u 100Base-TX/FX fast Ethernet
    • IEEE802.3ab 1,000Base-T
    • IEEE802.3z 1,000Base-SX/LX Gigabit
  • Wavelength: 850/1,310/1,550nm
  • MAC address table: 4K
  • Data buffer: 256K
  • Connector:
    • UTP: RJ-45, 10/100/1,000Mbps
    • Fiber: SC, 1,000Mbps
  • Cable:
    • UTP cable: Cat 5e or Cat 6 (maximum distance up to 100m)
    • Fiber:
      Multi-mode: 50/125, 62.5/125μm (maximum distance up to 550/224m)
    • Single mode: 8.3/125, 8.7/125, 9/125μm (maximum distance up to 120km)
    • Connector: FC/PC or SC or SFP port
  • Flow control:
    • Full duplex: IEEE802.3x
    • Half duplex: back pressure
  • Conversion mode: medium conversion
  • MTBF: 80,000 hours
  • LED:
    • FX LINK (fiber link action)
    • TP LINK1000 (twisted pair connection 1,000M)
    • TP LINK100 (twisted pair connection 100M)
    • TP ACT (twisted pair packet forwarding action)
    • FDX (Ethernet interface mode indicator on, full duplex/off, half duplex)
  • IEEE802.3 10Base-T Ethernet
  • IEEE802.3u 100Base-TX/FX fast Ethernet
  • IEEE802.3ab 1,000Base-T
  • IEEE802.3z 1,000Base-SX/LX Gigabit
  • UTP: RJ-45, 10/100/1,000Mbps
  • Fiber: SC, 1,000Mbps
  • UTP cable: Cat 5e or Cat 6 (maximum distance up to 100m)
  • Fiber:
    Multi-mode: 50/125, 62.5/125μm (maximum distance up to 550/224m)
  • Single mode: 8.3/125, 8.7/125, 9/125μm (maximum distance up to 120km)
  • Connector: FC/PC or SC or SFP port
  • Full duplex: IEEE802.3x
  • Half duplex: back pressure
  • FX LINK (fiber link action)
  • TP LINK1000 (twisted pair connection 1,000M)
  • TP LINK100 (twisted pair connection 100M)
  • TP ACT (twisted pair packet forwarding action)
  • FDX (Ethernet interface mode indicator on, full duplex/off, half duplex)
  • Input range: AC 170-240V or DC 36-72V
  • Output: DC 5V 2A
  • Power consumption: 5W
  • Ambient temperatures: 0 to +50
  • Storage temperatures: -20 to +70
  • Humidity range: 5 to 90%
  • Internal power: 30 × 110 × 140mm
  • External power: 26 × 70 × 93mm
