480W24V LED Switching Power Supply
Quantity:
Your message must be between 20 to 2000 characters
Contact NowBasic Info
Basic Info
Product Description
Product Description
Basic Specification
| White | White/Green |
|---|---|
| Output Frequency | 47-63HZ |
| Output Voltage | 24V |
| Input Voltage | 220V |
| Output Power | 401-500W |
| Output Current | 20A |
| Output Type | Multiple |
Detail Description
1. input voltage range: AC90-132V or AC180-264V (selected by switch)
2. AC input Frequency: between AC47Hz and 63Hz
3. AC input current: AC 6.5A under 115V or AC 4A under 230V
4. AC inrush current: AC 35A under 115V or AC 60A under 230V (cold-state started)
5. AC Leakage current: below AC 0.5mA under 240V
6. Adjustable range for DC output voltage: ±10% (based upon the input voltage)
7. Overload protection: The output can be cut off when it’s overloaded by 5-50% and revert automatically.
8. Overvoltage protection: The output can be cut off when it’s 115-135% of the rated voltage.
9. Time to start, rise and hold up: corresponding to 200 ms, 100 ms and 20ms
10. Voltage-withstanding characteristic: 1min under AC 1.5KV; IP- sheath: 1min under AC 1.5KV; OP- sheath: 1min under AC 0.5KV
11. Working temperature: between -10℃ and 60℃
12. Working humidity: between RH 20% and 90%
13. Safety characteristic: in accordance with GB4943, UL60950 and EN60950
14. EMC characteristic: in accordance with GB9254 and NE55022
15. Net weight: 950g
2. AC input Frequency: between AC47Hz and 63Hz
3. AC input current: AC 6.5A under 115V or AC 4A under 230V
4. AC inrush current: AC 35A under 115V or AC 60A under 230V (cold-state started)
5. AC Leakage current: below AC 0.5mA under 240V
6. Adjustable range for DC output voltage: ±10% (based upon the input voltage)
7. Overload protection: The output can be cut off when it’s overloaded by 5-50% and revert automatically.
8. Overvoltage protection: The output can be cut off when it’s 115-135% of the rated voltage.
9. Time to start, rise and hold up: corresponding to 200 ms, 100 ms and 20ms
10. Voltage-withstanding characteristic: 1min under AC 1.5KV; IP- sheath: 1min under AC 1.5KV; OP- sheath: 1min under AC 0.5KV
11. Working temperature: between -10℃ and 60℃
12. Working humidity: between RH 20% and 90%
13. Safety characteristic: in accordance with GB4943, UL60950 and EN60950
14. EMC characteristic: in accordance with GB9254 and NE55022
15. Net weight: 950g
Additional Information
| Payment Terms | T/T |
|---|---|
| Minimum Order | 1000pcs |
| Lead Time / Delivery Time | 7 Day(s) |
| Sample Available | YES |
| Delivery Details | If the quantity is large, the delivery date should be delayed reasonably. If normal, within 7 days. |
| Loading Info | Usually by sea. Of course,it can also be decided by the customer. |
| Packing Info | Each piece is packed in a small carton, and then a certain number of pieces are contained in a big carton. |
| Target Market(s) | Africa(except Middle East), Central & Southern Asia, Eastern Europe, Hong Kong/ Macao/ Taiwan, Japan & Korea, Latin America, Mainland China, Middle East, North America, Northern Europe, Oceania, Southeast Asia, Western & Southern Europe |
