Indoor Fix Installation LED Display :P1.8.P2.5.P3.P4.P5.P6.P7.62.P8.P10

Arise Technology Co., Ltd is a high-tech company dedicated in providing professional LED displays and comprehensive optoelectronic solutions.

Arise Technology owns strong execution, brilliant development strategies and programs, sustainable creation based on market demand. We spare no effort to provide customers with market-oriented innovative products with good reliability, suitable solutions and all-round service. Arise`s main products includes indoor and outdoor LED displays for fix installation, indoor and outdoor LED displays for rental business, stadium perimeter LED displays, and other special LED displays in accordance with customized requirements; LED display control system, related optoelectronic equipment, LED devices and components. We are ready to providing LED display solutions for oversea and domestic advertisement media, building advertising and lighting, municipal administration, hospital, hotel, bank, traffic, sports, entertainment, show, exhibition, etc.

We Arise Technology regards integrity in company staff, customers and suppliers as the enterprise foundations, market demands as the guide. We guarantee quality with profession and dedication and use enterprise culture to fill our brand. We keep striving, forging ahead, creating to provide customer with strong and unremitting support and backup.

Indoor P2.5 LED Display Parameters
Model F I-2.5
Parameters Speci.
Pixel Pitch 2.5mm
Pixel Composition 1R1G1B
LED Type 3-in-1 SMD2121(high contrast black LED)
Display brightness 1000cd/m² (adjustable)
Color Temperature 2500K to 10000K
Viewing Angle H: 160°; V:160°
Pixel Density 160000 pixels/m²
Minimum Viewing Distance ≥2.5 M
Module Size 160mm×160mm;160mmx80mm. Two versions.
Cabinet Size W480mm×H480mm×D90mm
Cabinet Weight 11.5 kg/cabinet
Cabinet Size 0.2304 m²
Cabinet Material Iron
Cabinet Aspect Ratio 1:1
Cabinet Resolution 192×192 pixels
Grey Scale 16bit(high refresh).14bit(common refresh)
Driving Mode 1/16 scan, constant current
Processing Depth 65536 scales
Colors 281.4 trillion
LED wave length R: 620~630nm G: 520~535nm B: 465~475nm
Brightness Control Manual/Automatic
Display contrast 5000:1
Frame Rate 50/60 Hz
Refresh Rate 3200 Hz(high refresh) .1000 Hz(common refresh)
Input Voltage 110~220VAC±15%
Input Power Frequency 50~60 Hz
Max. Power Consumption 170W/cabinet
Ave. Power Consumption 57W/cabinet
Life Span ≥100,000 hours
Input Signal RF,S-VIDEO,RGBHV,YUV,YC & COMPOSITION,etc
Communication Collection CAT5 Cable: ≤140m;
Multi-mode fiber ≤ 500m; Single mode fiber ≤ 20km )
Installation Method Hanging /wall mounted/other customized installation methods.
Protection Scale IP43
Operation Humidity 0℃~+45℃/10~90%RH
Storage Humidity -10℃~+55℃/10~90%RH
