P10 Indoor LED Display,One-stop LED display manufacturere,Arise Technology Co.,Ltd.

Get Latest Price

Payment Type:: T/T

Incoterm:: FOB

Min. Order:: 5 Square Meter

Min. Order:: 5 Square Meter

Delivery Time:: 15 Days

Transportation:: Ocean, Air

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Place of Origin:	CHINA
Productivity:	100000sqm/month
Supply Ability:	100000sqm/month
Payment Type:	T/T
Incoterm:	FOB
Certificate:	CE/ISO/ROHS/FCC/CCC/UL/ETL
Transportation:	Ocean,Air

Product Description

SMD 3528 RGB 3 in1 High Brightness Full Color P10 Indoor LED Display,One-stop LED display manufacturere,Arise Technology Co.,Ltd.

2D49CF6E-6519-447B-9866-6D40533EF39B

Module Parameters	Item	Parameters
	Pixel Pitch	10 mm
	Pixel Density	10000 Pixels/m²
	Pixel Composition	RGB 3 in1
	LED Specification	SMD 3528
	Module Resolution	32*16 Pixels
	Module Size(W×H)	320mmx160mm
	Peak Power Consumption	20 W
	Module Weight	0.4 Kg
Cabinet Parameters	Cabinet Type	Die-casting Aluminum Cabinet
	Flatness	≤0.5mm
	Cabinet Dimension (WHThickness)	960mm960mm130mm
	Cabinet Resolution	96*96 Pixels
	Cabinet Area	0.9216 m²
	Cabinet Weight	35 kg/m² (Steel Cabinet) 30 kg/m²(Aluminum Cabinet)
	Serviceability	Front/Back
	IP Rating	IP43, Indoor
Optical Parameters	White Balance Brightness	≥1500cd/m²
	Color Temperature	3200~9300K 3200~9300K Adjustable
	Color Processing	14 Bit; 16 Bit
	Optimum Viewing Distance	≥10 m
	Horizontal Viewing Angle	160⁰ (min 50% brightness)
	Vertical Viewing Angle	140⁰ (min 50% brightness)
	Luminance uniformity	≥97%
	Color Uniformity	±0.005Cx,Cy
	Contrast	5000:1
Electrical Parameters	Max. Power Consumption	400 W/m²
	Ave. Power Consumption	140 W/m²
	Output Voltage	DC 5V
Processing Performance	Driving Mode	Constant Current Drive 1/8 Scan

201407312131267711398

Competitive Advantage:

1) Price Advantage: Best competitive price of the market;

2) Performance Advantage: Best brightness, High refresh rate, high consistency, Big viewing angle;

3) Quality advantage: From material to finished product, from design to produce, we control all steps, that's the guarantee of the quality and reliability;

4) Service advantage: with professional service team for 24 hours service.

One-stop LED display manufacturere,Arise Technology Co.,Ltd.
