physicalpitch

8mm

operationg power source

AC90-260V 50-60HZ

physical density

15625pixels/m2

frame frequency

60-85HZ

led shape & size

SMD 3 in 1

refresh rate

240-1000HZ

led arrangement

1G1R1B

brightness adjustment

0-100% 8 levels automatic

module size

256 X 128 mm

gama conrrection

(-5.0~5.0)

module resolution

32 X 16

correction scale level

16 bits

drive mode

Dynamic 1/8 duty

constant current

color temperature

5000-9300k

brightness

1400cd/m2

brightness correction

pixel, module, cabinet correction

transparency ratio

30%

input source support

composite, S-Video, componet, VGA, DVI, HDMI, SDI, HD_SDI

contrast

2000:01:00

control distance

UTP CAT5E:100m, Multi-mode fiber: 500m, Single mode fiber: 10km

view angle, 50% brightness

140°/140°

operating temperature

(-40°~ +65°)

minimum view distance

8m

operating humidity

10-90%

gray scale

10bits/ 1024levels

operating life span

100,000hours

color capacity

1.07billion

MTBF

5000hours

maximum power consumption

780w/ m2

protection rate

IP31

ave. power consumption

260w/ m2

out of control rate

0.01%
