1x2 CWDM Device (3port)
  • 1x2 CWDM Device (3port)
1x2 CWDM Device (3port)

1x2 CWDM Device (3port)

Payment Type:
T/T
Incoterm:
FOB
Min. Order:
2 Piece/Pieces
Min. Order:
2 Piece/Pieces
Delivery Time:
7 Days
Transportation:
Air
Quantity:

Your message must be between 20 to 2000 characters

Contact Now
Basic Info
Basic Info
Place of Origin: shenzhen
Productivity: 2000pcs
Supply Ability: 2000pcs
Payment Type: T/T
Incoterm: FOB
Certificate: CE,ROSE
Transportation: Air
Product Description
Product Description

Flyin Optronics` Coarse wavelength division multiplexer (CWDM) utilizes thin film coating technology and proprietary design of non-flux metal bonding micro optics packaging. It provideslow insertion loss, high channel isolation, wide pass band, low temperature sensitivity and epoxy free optical path.

Features

Low Insertion Loss

Wide pass band

High Channel Isolation

High Stability and reliability

Epoxy-free on Optical Path


Applications

Line Monitoring

WDM Network

Telecommunication

Cellular Application

Fiber Optical amplifier

Acess Network


Performance Specifications

Parameter

Specification

Channel Wavelength

1260 to 1620

Center wavelength Accuracy

0.5

Channel Spacing

20

Channel Passband

13

Pass Channel Insertion Loss

0.6

Reflection Channel Insertion Loss

0.4

Channel Ripple

0.3

Isolation

Adjacent

30

Non adjacent

40

Inertion Loss Temperature Sensitivity

0.005

Wavelength Temperature Shifting

0.002

Polarization Dependent Loss

0.1

Polarization Mode Dispersion

0.1

Directivity

50

Return Loss

45

Maximum Power Handling

300

Opterating Temperature

-25 to 75

Storage Temperature

-40 to 85

Package dimension

5.5x34
