DS03M Waterproof&Waterproof IP Video Intercom System

Get Latest Price

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Product Description

What is the details of our Intercom

1. High resolution:960*576 pixels

2. Image sensor Sony DSP Effuo-E

3. Exceptional light sensitivity:0.005lux,day/night

4. High-efficiency IR illumination with automatically adjustable illumination level

5. Back light compensation, 3D noise reduction

6. Digital Wide Dynamic Range(DWDR)

7. Field of view adjustment:rotatable body

8. Vandal resistant: metal body.hidden fixing

9. Video recording by pressing the call button

10.Wide range of locks support

11.Outdoor, -40...+50

12.Power:12 V DC or Poe

General characteristics
Sensor	Color, 1/3 '' SONY 960H CCD, DSP Effio-E, Day / Night
Sensitivity	0.1 lux (day) / 0.01 (Night) 0 Lux (with incl. Backlight)
Resolution	650 TV lines (horizontal), 976*582 (effective pixels)
	Black Light Compensation,3D noise reduction
DWDR	Digital Wide Dynamic Range(DWDR)
Video
Compression Format	H.264 MP, Motion JPEG
Stream Video	Dual encoding: H.264 / MJPEG, H.264 / H.264, MJPEG / MJPEG
Resolution	960x576, 720x576 (Full D1), 704x576 (D1), 704x288 (2CIF),
	352x288 (CIF), 176x144 (QCIF)
Frame rate	Up to 25 / s for all resolutions (H.264)
Audio
Compression	G.711 (u-law, a-law), G.726
Additionally	Two-way audio channel
Network and interfaces
Network interface	10Base-T / 100Base-TX Ethernet port
Network Protocols	TCP, HTTP, FTP, SMTP, DNS, DHCP, PPPoE, POP3, RTP, RTSP, UDP, NTP, ARP
IR illumination
LEDs	IR LED Lattice-type (1 pc.)
Illumination Level	Automatically adjustable
Range	10 meters
Operation
PoE	PoE IEEE 802.3 AF
Operating temperature range	- 40 To + 50°C
Ingress Protection	IP65 , Metal coated with a corrosion-resistant polyester powder paint
Dimensions (WxHxD)	7316651 mm
Management	Professional Software Intercom (included)
	Field of View Adjustment: rotatable body
Components
Scope of delivery	Outside panel
	Switching box
	CD (with software and documentation)
	Package
