High precision Low Noise Deep Groove Ball Bearing 61918 619
  • High precision Low Noise Deep Groove Ball Bearing 61918 619
High precision Low Noise Deep Groove Ball Bearing 61918 619

High precision Low Noise Deep Groove Ball Bearing 61918 619

Min. Order:
1
Min. Order:
1
Delivery Time:
30 Days
Quantity:

Your message must be between 20 to 2000 characters

Contact Now
Basic Info
Basic Info
Place of Origin: China
Product Description
Product Description

High precision Low Noise Deep Groove Ball Bearing 61918,61919,61920,61921,61922 Single Row Sealed or Open

Quick Detail:

Product name: Deep groove ball bearing

Model number: 61918,61919,61920,61921,61922

Precision rating:P0 P6 P5

Clearance:C0 C1 C2 C3

Cage:Stamping steel,Brass,Nylon,Ceramic
Sealed type:RS,2RS,Z,2Z
Vibration:Z1V1,Z2V2,Z3V3
Material:Gcr15,Stainless steel,Carton steel,Plastic,Ceramic

Description:

Deep groove ball bearing is a kind of the most common rolling bearing. The basic type of deep groove ball bearing is composed of an outer ring, a ring, a group of steel ball and a group of retainers. Deep groove ball bearing has a single row and double row two types, and also has sealed bearing and open bearing, open refers to the bearing without sealing structure,sealing type deep groove ball into the dust seal and oil seal. Dust seal cover material for steel plate stamping, plays only a simple prevent dust from entering the bearing raceway. Oil proof type contact type oil seal, can effectively prevent bearing grease inside the spillover.

Single row deep groove ball bearing type code is 6, double row deep groove ball bearing code is 4. It has the advantages of simple structure, convenient use, and most popular, it’s the most widely used one kind of bearing.

Applications:

Deep groove ball bearing can be used for transmission, instruments and meters, electric machinery, household electrical appliances, internal combustion engines, transportation vehicles, agricultural machinery, construction machinery, engineering machinery, roller skate,yo-yo etc.

Specifications:

Bearing No. Main Dimension (mm) Weight (kg)
Bore Outer Diameter Width
d D W
mm mm mm
61918 90 125 8 0.559
61919 95 130 18 0.586
61920 100 140 20 0.786
61921 105 145 20 0.805
61922 110 150 20 0.840

Competitive advantages:

Our company product and export bearings for 20years,so we have a deep knowledge of bearing.we can guarantee the quality and the price ,and we ensure our production can meet your requirement. In addition ,we can manufacture the production according your requirement.

Our company main production:

Deep Groove Ball Bearing / Angular Contact Ball Bearing/ Taper Roller Bearing/ Spherical Roller Bearing /Cylindrical Roller Bearing / Thrust Ball Bearing /Thrust Roller Bearing /Self-aligning ball bearing/Self-aligning roller bearing/Pillow Block Bearing /Needle Roller Bearing /Tracking Roller Bearing/ Auto Bearing Etc.

Welcome to inquire bearing.

Your inquiry related to our product & price will be replied within 24 hours.
