Air Mini 4 Pole Circuit Breaker Switch Automatic Reset For Household 4KA 6KA 10KA
Quick Detail:
|
Place of Origin: |
Zhejiang China (Mainland) |
Brand Name: |
JIELI |
Model Number: |
JL-MUN |
|
Type: |
Mini 3 phase circuit breaker |
Poles Number: |
4 |
OEM: |
Available |
|
Certificate: |
CE,CCC,ISO9001 |
Tripping Curve: |
B,C,D |
Standard: |
IEC60947 |
|
Breaking capacity: |
4KA,6KA,10KA |
Quality control: |
In house |
|
|
Description:
JL-MUN 3 phase circuit breaker has protective function as shortage as overload.
And JL-MUN 3 Phase circuit breaker is used in lighting distribution system in commerce and dwelling, and protect fractional electrical motors. High protective grade IP20, high breaking capacity, reliable sensitive action, convenient, multi pole assembling, long life ect.
JL-MUN 3 Phase circuit breaker mainly adapted to circuit of AC 50Hz,250V in single pole, 415V in double, three, four poles for protecting overload and short circuit.
Also JL-MUN 3 Phase circuit breaker used in on or off the electrical apparatus and lighting circuit under the normal conditions.
Specifications:
|
|
Standard |
|
IEC/EN 60898-1 |
|
Electrical features |
Rated current in |
A |
1 2 4 6 10 16 20 25 32 40 50 63 |
|
Poles |
|
1P 2P 3P 4P |
|
|
Rated voltage Ue |
V |
230/400 |
|
|
Insulation coltage Ui |
V |
500 |
|
|
Rated frequency |
Hz |
50/60Hz |
|
|
Rated breaking capacity |
A |
3000 4500 6000 |
|
|
Rated impulse withstand voltage (1.2/50)Uipm |
V |
6000 |
|
|
Dielectric test voltage at and ind.Freq.for 1min |
KV |
2 |
|
|
Pollution degree |
|
2 |
|
|
Themo-magnetic release characteristic |
|
B C D |
|
|
Mechanical features |
Electrical life |
|
6000 |
|
Machanical life |
|
10000 |
|
|
Contact position indicator |
|
Yes |
|
|
Protection degree |
|
IP 20 |
|
|
Reference temperature of setting of thermal element |
°C |
30 |
|
|
Ambient temperature(with daily average≤35°C) |
°C |
-5~+40 |
|
|
Storage temperature |
°C |
-25...+70 |
|
|
Installation |
Terminal connection type |
|
Cable/U-type busbar/Pin-type busbar |
|
Terminal size top/bottom for cable |
mm² AWG |
25 18-3 |
|
|
Terminal size top/bottom for busbar |
mm² AWG |
25 18-3 |
|
|
Tightening torque |
N*m In-lbs. |
3.0 22 |
|
|
Mounting |
|
OnDIN rail FN 60715(35mm) by means of fast clip device |
|
|
Connection |
|
From top and bottom |
