960P Digital Input HDD Recorder NVR Network Video Recorder PTZ Control Interface
Application:
- Office Building: More office staff. Application of the product on the screen monitoring and recording. Fire prevention office, robbery, explosions and other emergencies that may occur.
- Railway Stations:Belong to the personnel concentration areas, more in need of real time monitoring station records, prevent emergencies.
- Shopping center: Auxiliary business management of the store, at the same time, understand the market operation, also can better understand consumers' consumption trend.
- meeting: Real-time record of the meeting, storage records, when needed, can play back to watch.
Product Features:
- Support multi-browser(IE, Chrome, Firefox, Safari)
- Support all kinds of mobile monitor(iPhone, Windows Mobile, BlackBerry, Symbian, Android)
- H.264 Compression
- Support main stream and extra steam encode synchronously
- Support TV, VGA & HDMI output synchronously
- Similar WINDOWS operating style, powerful right button menu function of mouse for easier use
- Device port: Support 1 SATA, can connect 1 maximum 4T HDD, support 2 USB2.0 port, can do the USB mouse, backup, burn, upgrade etc operation stably
SPECIFICATIONS
|
Performance Parameters |
||
|
System |
Main processor |
Hi3515A |
|
Screen display |
1/4 |
|
|
Video |
Video standar |
PAL(625TVL,50 Fields / sec. ;NTSC(525TVL,60 Fields / sec. ) |
|
Video quality |
Monitor :D1;VGA: HD;HDMI:HD |
|
|
Coding capacity |
1080P/720P/960H/D1/HD1/CIF/QCIF |
|
|
Digital input |
4*960P |
|
|
Motion Detection |
Each screen can be set to 192 (16 × 12) detection area; multi-level sensitivity can be set |
|
|
Video playback |
Video mode |
Manual> Alarm> Motion detection> timing |
|
Local Playback |
1ch |
|
|
Video inquiry |
Point-in-time retrieval, calendar search, event search, channel search |
|
|
Interface |
Video input |
No |
|
Video output |
1ch BNC output,1ch SPOT output,1ch VGA output, 1ch HDMI output(1920*1080P) |
|
|
Audio input |
1ch RCA |
|
|
Audio output |
1ch RCA audio output |
|
|
Alarm input |
NO |
|
|
Alarm output |
NO |
|
|
Network interface |
RJ45 10M/100M/1000M |
|
|
PTZ control |
One RS485 ptz control interface |
|
|
USB interface |
2*USB interface |
|
|
HDD |
1 SATA (3TB) |
|
