Rosemount Industrial Pressure Transmitter 3051C with the best process connection for pressure , flow , and level

Quick Detail:

  • Performance up to 0.04% accuracy
  • Total performance of ±0.15%
  • Installed five-year stability of 0.125%
  • Unmatched Dynamic Performance
  • Coplanar platform enables integrated pressure, flow, and level solutions
  • Optional PlantWeb Functionality to increase plant productivity
  • Responds up to eight times faster than the typical pressure transmitter


Description:

The Rosemount 3051C smart pressure transmitter combines advanced technology with the versatile Coplanar ™ process connection to create a new standard in pressure measurement technology. Even under the most demanding conditions, the performance specifications of the 3051C provide unmatched long-term stability and reliability.
The 3051C is capable of differential, gage, or absolute pressure measurement. Utilizing advanced capacitance sensor technology (piezoresistive sensors for absolute pressure models) the 3051C is accurate up to ±0.04% resulting in total operating performance, the true measure of "real-world" transmitter performance, of ±0.15%. Additionally, the Rosemount 3051 pressure transmitter has an installed five-year stability of ±0.125% demonstrating the ability to maintain performance over a five year period under the most demanding process conditions. The high accuracy and stability of the 3051C equates to reduced variability, lower operating and maintenance costs, and improved plant safety.
The 3051C can utilize either traditional flanges or Rosemount's versatile Coplanar ™ platform designed to enable the best process connection for pressure, flow, and level applications. Right out of the box, the solution arrives factory calibrated, pressure-tested, and ready to install. The Rosemount 3051C smart pressure transmitter is also available in a number of materials and a wide range of hazardous area certifications are available.
Output options available to the Rosemount pressure transmitter 3051C include 4-20mA or 1-5VDC with HART protocol, Profibus, or FOUNDATION fieldbus. The 3051C offers so many options that it can be configured for any application.


Applications:

The Rosemount 3051C smart pressure transmitter can utilize either traditional flanges or Rosemount's versatile Coplanar ™ platform designed to enable the best process connection for pressure, flow, and level applications. Right out of the box, the solution arrives factory calibrated, pressure-tested, and ready to install. The Rosemount 3051C smart pressure transmitter is also available in a number of materials and a wide range of hazardous area certifications are available.


Specifications:

3051CD

Differential pressure transmitter

3051CG

Gage pressure transmitter

3051CA

Absolute pressure transmitter

code

Pressure range

3051CD

3051CG

3051CA

0

-3----3inH2O/0.1inH2O

Not present

Not present

1

-25---25inH2O/0.5inH2O

-25—25inH2O/0.5inH2O

0—30psia/0.3psia

2

-250—250inH2O/2.5inH2O

-250—250inH2O/2.5inH2O

0—150psia/1.5psia

3

-1000—1000inH2O/10inH2O

-407-1000inH2O/10inH2O

0—800psia/8psia

4

-300—300psi/3psi

-14.7—300psi/3psi

0—4000psia/40psia

5

-2000—2000psi/20psi

-14.7—2000psi/20psi

Not present

code

Output

A

4—20ma,with HART agreement digital signal

M

1—5Vdc,with HART agreement digital signal

F

FF fieldbus

W

profibus

code

Structure parts material

Process flange type

Flange material

Liquid/gas discharge valve

Flange joint material

5

coplane

Electroplate carbon steel

Stainless steel

Electroplate carbon steel

2

Coplane

Stainless steel

Stainless steel

Stainless steel

3

coplane

Hastelloy C

Hastelloy C

Hastelloy C

4

Coplane

Monel

Monel

Monel

8

coplane

Electroplate carbon steel

Hastelloy C

Electroplate carbon steel

7

coplane

Stainless steel

Hastelloy C

Stainless steel

0

Replace flange

code

Diaphragm material

2

316L stainless steel

3

Hastelloy C

4

Monel

5

Tantalum

6

Gold plated monel

7

Gold plated stainless steel

Measurement Type

Differential, Gage, Absolute, Level, Flow

Output

4-20 mA HART, FOUNDATION™ fieldbus, PROFIBUS PA, 1-5 Vdc HART Low Power

Reference Accuracy

± 0.065% of span with 0.04% Optional

Total Performance

± 0.15% of span

Long Term Stability

± 0.125% of URL for 5 years

Rangedown

100:1



Competitive Advantage:

1. Manufactured by Rosemount
2. Performance up to 0.04% accuracy
3. Total performance of ±0.15%
4. Coplanar platform enables integrated pressure, flow, and level solutions
5. Optional PlantWeb Functionality to increase plant productivity
6. Responds up to eight times faster than the typical pressure transmitter
