Simplex ST Fiber Optic Terminal Box with 12port Rack Mounte
- Min. Order:
- 1
- Min. Order:
- 1
- Delivery Time:
- 30 Days
Quantity:
Your message must be between 20 to 2000 characters
Contact NowBasic Info
Basic Info
| Place of Origin: | Guangdong, China |
|---|
Product Description
Product Description
Simplex ST Fiber Optic Terminal Box with 12port Rack Mounted Structure
Description:
Rack Mounted Terminal Box can be applied in the branch connection of fiber termination, working as distribution box.
Quick Detail:
- Name: ST Fiber Terminal Box
- Suitable Adapter: FC, SC, ST, LC
-
Fiber to the home(FTTB)
-
Optical network
- Adapter port type: FC(Simplex), ST(Simplex), SC(Simplex/Duplex), LC(Duplex)
- Max capacity: 1U(12core/24core), 2U(48core), 3U(72core), 4U(96core)
Features:
- Easy to repeated opening and using
- Could deploy valve and Grounding device
- Apply for SC/ST/FC/LC pigtail and adapter
- 19" standard slide-out design, easy and convenient on assembling
- Cabinet surface covered with electrostatic powder coating, luxury and beautiful
Application:
- Fiber to the home(FTTB)
- Optical network
- Local area networks
- Wide area networks
Specification:
| Type | RMF-1U | RMT-2U |
| Size(mm) L*W*H |
480*250*1U | 480*250*2U |
| Max Capacity (Core) | 24 | 48 |
| Outer Carton Dimension(mm) | 485*425*305/5pcs | 485*675*305/5pcs |
| Outer Carton Volume(m3) | 0.063 | 0.1 |
| Outer Carton Weight(Kg) | 14.2/5pcs | 21/5pcs |
Technical Data:
| Model | RMF-1U |
| Size(mm): L*W*H | 430*250*1U |
| Max capacity: | 24core(1U) |
| Optical fiber winding radius: | ≥40mm |
| Fiber length left in tray: | none |
| Fiber length left in tray: | ≥1.6m |
| Fiber capacity: | 48 cores |
| Working temperature: | - 400°C ~ + 600°C |
| Lateral pressure-resistance: | 500N |
| Shock-resistance: | 750N |
Shipping:
- Door to Door: by express (such as DHL, UPS, TNT, FedEx etc.)
- Airport to Airport: by air
- Seaport to Seaport: by sea (our location Shenzhen is a seaport.)
