P12.5 Outdoor LED Signs Display Programmable 1R1G1B Constant Current Driving
Quick Details:
1.12.5mm pixel rgb, hd, big density, very bright
2. 2 years' warranty for entire screen.
3. on-site professional service.
4. adequate spare parts supply.
5. hotline service, fast response.
6. technical support on upgrades and replacement.
7. regular maintenance service.
Application and function:
Suit for advertisement, shopping mall, banks, schools, bus station, airport, gym, market, stage, stadium, exhibition, TV-Show, mansion video wall, factories, monitoring centers, hospitals, bars etc.
1. Video display for advertisement, Live broadcast for news, sport, concert…
2. Stage background
3. Information display for time, schedule, text
4. Dynamic display for logo, text, video
Function and Technology Character:
1. Multiform file formats, such as VGA, Video, AVI, MOV, MPG, DAT, VOB and so on are comprehensive.
2. Information source can be camera, video, VCD, DVD, LD, TV and so on.
3. Show everything with your PC does synchronously.
4. Brightness, contrast, saturation can be adjust by itself and manual.
5. Clear picture without flicker and distortion.
6. Super correcting technology for distortion.
7. Multiform language editions, such as English, French, Germany, Greek, Russian, etc
8. One interface for sound signal and two for video signal at least. Connected and controlled by PC via Lan and remote control.
Specifications:
| Model NO.AD-O-F-P12.5 Outdoor LED Sign / Outdoor DIP LED Advertising Signs | |
| Pixel pitch | 12.5mm |
| Module dimension | 200mm*200mm |
| Cabinet dimension | 1000mm*1000mm |
| Pixel Density | 6400 Dots/sqm |
| LED standard | DIP 346 |
| Brightness | 6500cd/ sqm |
| Protection level | IP 65 |
| Pixel configuration | 1R1G1B |
| Control mode | Synchronous/Asynchronous |
| Module/Resolution | 16*16 |
| Cabinet/Resolution | 80*80 |
| Module/Cabinet | 5*5 |
| Driving method | constant driving 1/4 scan |
| Viewing angle | H:110° V:55° |
| The best viewing distance | 12 to 150m |
| Power Consumption | Max.600w/ sqm |
| Averagely.200w/sqm | |
| Refreshing rate | 800Hz |
Basic Promise from RIYUEGUANGHUA:
A: Full automatic production to control our high quality, best color consistency and get better performance.
B: Energy saving, low power consumption and long lifespan 100,000 hours (about 10 years).
C: We guarantee that the equipment we provide are brand new, complete and unused.
D: Good heat dissipation capability and high waterproof because of the unique design of vent fan (like shutter).
E: Our quality control throughout every process from materials-production- test-package-delivery(led lamp, module,
cabinet, led screen)
Why choose RIYUEGUANGHUA?
1) 5 years' production experience, have passed certifications CE/ROHS/FCC/Supplier assessment.
2) Full automatic production to control our high quality, best color consistency and get better performance.
3) Energy saving, low power consumption and long lifespan 10,000 hours (about 10 years).
4) We guarantee that the equipment we provide are brand new, complete and unused.
5) Good heat dissipation capability and high waterproof because of the unique design of vent fan (like shutter).
6) Our conduct strict quality control throughout every process from led lamp, module, cabinet to screen.
Quality:Strict Produce Requirments&Stable Performances
1.5 process to check the LED.
2.Automatic devices to pack the LEDs in board.
3.The same patches LEDs in different devices to plug in boards.
4.Workers check
5.Fixtures to fix leds in good positions and put in wave-soldering devices.
6.Workers check
7.Weatherproof processs: Dust proof, waterproof, decay proof.
8.Base bracket&covers glue process by fixture devices
9.Workers test for all performances accoriding to clients' requirments.
10.LED Modules aging tests 24hrs.
11.Cabinets aging tests 72hrs to check screen performances.
