Video Playing Outdoor P16 LED RGB Display

Get Latest Price

Payment Type:: L/C, T/T, Western Union

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Place of Origin:	Shenzhen, China
Payment Type:	L/C, T/T, Western Union

Product Description

Video playing outdoor p16 led rgb display

Specifications
Pixel pitch 16mm LED screen
Waterproof for outdoor use
2 years warranty
Available model:
For indoor use: P3/P4/P5/P6/P7.62/P10 ( SMD 3 in 1)
For outdoor use: P10/P12/P16/P20/P25 (DIP)

Low energy consumption, long lifespan, stable performance
Appearance can be customized, flexible, with a strong visual impact
Easy installation, easy maintainance, easy using
Quick and easy assembly, removing System, save loading time

Using Range
Widely used in large venue, stadiums, bank, government,
Terminal, dock, station, stock market, medical systems,
Electricity, exhibition etc.

Items		Outdoor use LED screen
Model		P10	P12	P16	P20	P25
Module	Pixel Pitch	10mm	12mm	16mm	20mm	25mm
	Pixel Density (dots/sq.m)	10000	6944	3906	2500	1600
	LED encapsulation	DIP346	DIP346	DIP346 /546	DIP346 /546	DIP546
	LED Type	DIP	DIP	DIP	DIP	DIP
	Module Size(mm)	160x160	192X192	256x256	320x160 320x320	200x200
	Module Resolution (dots)	16x16	16x16	16x16	16x8 16x16	8x8
	Pixel configuration	1R1G1B	1R1G1B	1R1G1B	1R1G1B 2R1G1B	2R1G1B
Main technical parameter	Optimum Viewing distance	>8m	>10m	>15m	>18m	>22m
	Brightness (nit)	>7500	>7000	>6500	>6500	>5000
	Working temp. (°C)	-20~+60	-20~+60	-20~+60	-20~+60	-20~+60
	Ave.Power consumption (w/sq.m)	300	300	350	300	200W
	View angle	120°/ 90°	120°/ 90°	120°/ 90°	120°/ 90°	120°/ 90°
	Refresh rates	>1200Hz	>2000Hz	>3000Hz	>3000Hz	>3000Hz
	Life span	100000 hours	100000 hours	100000 hours	100000 hours	100000 hours
