Ultra Thin Commercial Stage Screen Rental LED Display Panel For Advertising High Resolution
1. Wide application: it can be used for any rental application of stage show: such as main rental led display, side screen, floor screen, arc screen stage design etc.
2. Easy and Fast: for both installation and dismantling, without any tools, it takes only 10 seconds to assembly, hanging, pile up and fix installation available.
3. High structure performance: easy connection of each components, modules and HUB card without flat cables, modules and systems without power cable.
4. Both indoor and outdoor series are compatible, outdoor SMD and DIP screen with IP65 weatherproof level, so it can be used normally in rainy days.
5. Floor led screen can bear 1 ton weight, IP65 weatherproof level.
LED display Application
P5 Rental LED Display could be used in indoor environment such as municipal mansion,
enterprise hall, show room, cinema, stage, with various real-time signal sources and the SMD
encapsulation technology, its purpose is to play the important news or events or TV program .
| Pixel Information | Pixel Pitch | 5mm |
| Pixel Density | 40000 Pixels/m2 | |
| Pixel Configuration | 1R1G1B | |
| LED Wavelength | Red: 615 nm - 635 nm | |
| Green: 520 nm - 535 nm | ||
| Blue: 465 nm - 475 nm | ||
| LED Module | Module Size(mm) | 160 (Width) × 160 (Height) |
| Module Resolution | 32(Width) × 32 (Height) | |
| Cabinet | Cabinet Size(mm) | 640 (Width) ×640(Height) |
| Cabinet Resolution | 128 (Width) × 128 (Height) | |
| Total QYT Module Per Cabinet | 4 (Width) ×4(Height) | |
| Cabinet Weight | 30kg/m2 | |
| Cabinet Material | Die-casting Aluminum LED Display | |
| Power | Input Voltage | 100-240V AC, 50/60Hz |
| Max Power Consumption | 1100 Watt/m2 | |
| Avg. Power Consumption | 650 Watt/m2 | |
| Brightness | ≥3500cd/m2 | |
| Brightness Uniformity | Luminance Discrepancy < 5% | |
| Best Viewing Angle | Horizontal:140°,Vertical:70° | |
| Viewing Distance | 5 - 15 meters | |
| Ambint Conditions | Temperature Range | Working:-20deg. to +60deg |
| Operating Humidity | 10%90%RH | |
| Ingression Protection Grade | IP30 | |
| Processing | Scanning Mode | 1/8 scanning |
| Refresh Frequency | 600-1200HZ, Adjustable(depends on control system) | |
| Signal Input | DVI, Composite Video for Live Video | |
| Supported Networking | Through LAN/WAN, RS 232/RS485 | |
| Controller | Linsn or Nova |
Advantage :
1) Wide viewing angles and the horizontal angle can reach 140° , The images effect will not change largely in the range.
2) High density make the images softer and vivider.
3) Single-lamp maintenance with low cost.
4) Good heat dissipation capability because of the unique design of vent fan (liking shutter).
5) Environmental-friendly and energy-saving.
