Refrigeration controls Danfoss Oil Differential Pressure Control MP Series

Specifications:

Danfoss oil differential pressure control(MP Series)

MP-MP-A pressure difference controller,
MP 54 and MP 55 oil differential pressure controller is a type of safety switch to prevent the refrigeration compressor oil pressure is too low. If the oil pressure drops below the set value, at a certain time interval, the pressure difference controller operation, the compression.

MP 54 and MP 55 oil differential pressure controls are used as sefety switches to protect refrigeration compressors.

1. MP 54 differential pressure control, fixed differential, low differential pressure
2. Control voltage: 230 V or 115 V a. C. Or d. C.
3. Permissible voltage variation: +10 - -15%.
4. Max. Working pressure = 17 bar.
5. Max. Test pressure = 22 bar.
6. Operation range, LP side: -1 - 12 bar PE.
7. Temperature compensation: The time relay is temperature-compensated in the range -40 - +60° C.
8. Screwed cable entry: Pg 13.5.
9. Max. Bellows temperature: 100° C.
10. Enclosure: IP 20 to IEC 529.
