MOSFET 55V IRFL024ZTRPBF
- Payment Type:
- T/T, Western Union, Escrow
- Min. Order:
- 100 Piece/Pieces
- Min. Order:
- 100 Piece/Pieces
- Delivery Time:
- 1 Days
Quantity:
Your message must be between 20 to 2000 characters
Contact NowBasic Info
Basic Info
| Place of Origin: | Mexico |
|---|---|
| Supply Ability: | 30000 Piece/Pieces per Day |
| Payment Type: | T/T,Western Union,Escrow |
Product Description
Product Description
Specifications 1: MOSFET N-CH 55V 5.1A SOT223
2: IRFL024ZTRPBF IR 1147+
3: New and Original in stock
2: IRFL024ZTRPBF IR 1147+
3: New and Original in stock
| Datasheets | IRFL024ZPbF |
|---|---|
| Product Photos | SOT223-3L |
| Product Training Modules | High Voltage Integrated Circuits (HVIC Gate Drivers) |
| Design Resources | IRFL024Z Saber Model IRFL024Z Spice Model |
| Standard Package | 2,500 |
| Category | Discrete Semiconductor Products |
| Family | FETs - Single |
| Series | HEXFET® |
| Packaging | Tape & Reel (TR) |
| FET Type | MOSFET N-Channel, Metal Oxide |
| FET Feature | Logic Level Gate |
| Drain to Source Voltage (Vdss) | 55V |
| Current - Continuous Drain (Id) @ 25° C | 5.1A |
| Rds On (Max) @ Id, Vgs | 57.5 mOhm @ 3.1A, 10V |
| Vgs(th) (Max) @ Id | 4V @ 250µA |
| Gate Charge (Qg) @ Vgs | 14nC @ 10V |
| Input Capacitance (Ciss) @ Vds | 340pF @ 25V |
| Power - Max | 1W |
| Mounting Type | Surface Mount |
| Package / Case | TO-261-4, TO-261AA |
| Supplier Device Package | SOT-223 |
| Dynamic Catalog | N-Channel Logic Level Gate FETs |
| Other Names | IRFL024ZTRPBF-ND IRFL024ZTRPBFTR |
