Ytterbium fiber laser marker 10/20W for logo making

Specifications 1.long useful life

2. high quality with high speed,no noise

3. low power consuption

4.IPG fiber laser ,imported Galvo Scann

 Technical Parameters Laser:ytterbium-doped fiber
Laser Power:10W/20W
Laser Wavelength:1055-1070nm
Laser Repetition Rate:20-200KHZ
Marking Area:110×110mm
Marking Wire-speed:≤12000mm/s
The Min. line Width:0.012mm
The Smallest Characters:0.1mm
The Repeat Accuracy:±0.003mm
The Whole Power:500W/600W
Operating temperature: 0-45°C
Operating humidity:   5-95%(free of condensed water)
Power supply:AC220V±10% ,50Hz
Net weight:   127Kg
Dimension:900×700×1300mm
          Applicable Field It is widely used in mark field of smooth finish and high precision, such as steel, copper,
aluminum, gold and silver, and most other metals, plastics, ceramics, electronic equipment.
And be suitable for watches and clocks, mold, bitmap marking, packaging, health care,
tobacco,Sanitary Ware, food, electronics, gifts and other industries
