40V 420Ma LED T8 Tube Driver isolated ip67 waterproof LED Tube Driver with CE ROHS

Specifications 100% full load burn-in test

Suitable for LED Tube Driver

Fully encapsulated with IP67 level

Constant current design

Specification

Max Output Power	23W
Input Voltage	AC90-264V
Output Voltage	DC30-40V
Max output Current	420mA
Efficiency	88%
Power Factor	0.95
Dimension(mm)	230*17.5*10MM(L*W*H)
MTBF(Ta=25°C)	≥438.Khrs, MIL-HDBK-217F(25°C)
Warranty Time	2 years warranty
Certification	ROHS, GS, CB, CE, FCC, PSE
Protection	OCP, OVP, SCP
Working Temperature	-20~+65°C
Voltage Tolerance	± 4%
Working Humidity	10~98%RH  non-condensing

      Advantage       1.Our aims are to provide every customer high quality, reasonable price and excellent service.   2.We can provide OEM and ODM products according to customer requirements   3.We can guarantee to send the goods on time. And also accept any transportation ways that you require.     Environment   1>Working Temperature: -20~+65°C
2>Working Humidity:  10~98%RH  non-condensing
3>Storage Temp., Humidity:  -30~+65°C, 10~95%RH
4>TEMP. Coefficient: ± 0.03%/o C ±0.03%/°C(0~50°C)
5>Vibration: 10 ~ 500Hz, 2G 10min. /1cycle, period for 60min. Each along X, Y, Z axes     Application
