alibaba express p16 programmable high birghtness waterproof multi line scrolling double sided led digital billboard

Specifications double sided led digital billboard

1.CE,ROHS,UL

2.Easy operation,Stable capability

3.3 years warranty

4.high brig

alibaba express p16 programmable high birghtness waterproof multi line scrolling double sided led digital billboard

Numbers	Technical indexes	Specification
1	Pixel pitch	16mm
2	Module size	256mm×128mm
3	Module resolution	16×16
4	Module density	3906dots/sqm
5	Pixel configuration	1R1G1B
6	Red wavelength	625±2nm
7	Green wavelength	525±2nm
8	Blue wavelength	470±2nm
9	Colors	16777216
10	Best viewing distance	more than 10 m
11	Horizontal viewing angle	140°
12	Vertical viewing angle	70°
13	Maximum power consumption	≤900W/m2
14	Brightness	≥8000cd/m2
15	Gray scale	16bits of per color
16	Color temperature	6500K
17	Control method	Synchronization or Asynchronization
18	Driving method	1/4 scanning
19	Frame frequency	480Hz
20	Refresh frequency	≥2000 Hz
21	Working voltage	AC220V/110V±10%
22	IP grade	IP65
23	Working temperature	-20°C~80°C
24	MTBF	More than 10,000 hours
25	Life span	More than 100,000hours


                Features High and adjustable brightness can meet the demands of the changing requirement of customer in different environments,especiall . No mosaic due to excellent flatness and nice uniformity of light-emitting Outdoor advertising display screenWide viewing angles and the horizontal angle can reach 120°m. The images effect will not Change largely in the range. Virtual pixel can be adopted for outdoor displays to increase the high resolution up to four times of real pixel, making the images softer and vivider Single-lamp maintenance with low cost. Good heat dissipation capability because of the unique design of vent fan (liking shutter). Environmental-friendly and energy-saving.
