Hot sells portable P10 flexible light weight led video curtain

Get Latest Price

Payment Type:: L/C, T/T, Western Union

Min. Order:: 1 Square

Min. Order:: 1 Square

Delivery Time:: 10 Days

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Place of Origin:	Guangdong, China (Mainland)
Supply Ability:	50000 Square Meter/Square Meters per Month
Payment Type:	L/C,T/T,Western Union

Product Description

Specifications 1.Easy installation&Packing

2.Friendly operation

3.Longer life,lower consumption

4.DMX control

5. 2 years warranty

Hot sells portable P10 flexible light weight led video curtain
1. Technical Parameters

Part Number	ASR-ID2S
Pixel Pitch	10mm
LED Configuration	1R1G1B 3-IN-1 SMD
Pixel Density	10,000 pixels/ m²
Cabinet size	640mm(width)640mm(Height)90mm(Depth)
Cabinet marterial	Anodizing Aluminum profile
Cabinet weight	≤10kg
Driving Method	1/2 scan, constant current
Installation Height
Foot build-up	Max. 25 tiles high
Truss build-up	Max. 25 tiles high
Optical Ratings
Brightness	3000 nits≤Y≤5500nits
View Angle	140° (min 50% brightness)/140° (min 50% brightness)
Gray Scale	65,536 levels per color
Display COLOR	281 trillion
Luminousness	20%
Contrast ration	4000 : 1
Power Supply
Operation Power	90-240V / 50-60Hz
Max. Power Consumption
Average Power Consumption	200W/cabinet
Control System
Control Mode	Synchronous display with control PC by DVI
Frame Update Frequency	60~85Hz
Screen Refresh Frequency	2500-4000Hz
Gamma Correction	-5.0~+5.0
Support Input	Composite, S-Video, Component, VGA, DVI, HDMI, HD_SDI
Recommended Min Viewing distance	10m
Support VGA Mode	1024×768, 1280×1024, 1600×1200, 1920×1280
Brightness Correction	Pixel, Module, Cabinet
Environmental
Operating Temperature	-20°~+60°
Operating Humidity	10~95% RH
Operating Life	100,000 hours to 50% of initial brightness
MTBF	>10,000hrs
Protection Level	IP43, IP65 both
Out of Control Rate	<0.02%
